80tVB347 Ball Thrust Bearing Type TVB

🔍

80tVB347

Bore Diameter:203.2 mm

Outside Diameter:295.275 mm

Width:76.2 mm

Weight:15.6 kg

Min. Order:1 Piece

The 80tVB347 Thrust ball bearings are widely used in various small and medium-sized equipment requiring axial load capacity, including: automotive steering systems, machine tool spindles, industrial gearboxes, crane hooks, centrifuges, and precision instruments.

The 80tVB347 bearing is a Ball Thrust Bearing Type TVB with an inner diameter of 203.2 mm , an outer diameter of 295.275 mm, a width of 76.2 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic axial rated load is approximately 501471 N, its static axial rated load is approximately 1697323 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

203.2 mm

Outside Diameter:

295.275 mm

Thickness:

76.2 mm

Weight:

15.6 KG

Dynamic load Capacity, axial:

501471 N

Static load Capacity, axial:

1697323 N

Specifications:

Structure:

Single direction thrust ball bearings

Number of Rows:

One

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Metric

Series:

TVB

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

80tVB347 bearings ( 203.2 mm x 295.275 mm x 76.2 mm) have the advantages of Suitable for high-speed applications, capable of withstanding unidirectional axial loads, with low friction and easy installation, and are therefore widely used in the Machine tool spindles, automotive steering systems, pumps, industrial machinery and instruments.

Part Number	80tVB347
Bearing Type	Ball Thrust Bearing Type TVB
Interchangeable	TIMKEN 80tVB347
Manufacturer Part Code	80 TVB 347
Series	TVB
Units	Metric
Tolerance class	PN (ABEC-1)
C_0a Axial Static [lbf]	381558
C_a Axial Dynamic [lbf]	112730
d φ Inside [inch]	8.0000
D Φ Outside [inch]	11.6250
T Width [inch]	3.0000
r Fillet Radius [inch]	0.2520
E (Max) Shoulder Diameter Housing [inch]	8.7480
H (Min) Shoulder Diameter Shaft [inch]	10.7519
Weight [lb]	34.3918

The 80tVB347 Thrust ball bearings mainly consist of a shaft ring (which mates with the shaft), a housing ring (which mates with the bearing housing), steel balls, and a cage. They feature a separable design for easy installation and maintenance. Some models include dust covers or sealed structures.

Thrust ball bearings have high axial load capacity, are suitable for bearing pure axial loads, have high limiting speeds, low friction coefficients, and smooth operation. Their separable structure simplifies installation, results in a compact size, and minimizes space requirements.

Share this product to:

Let more people see your product

How can you buy 80tVB347 Ball Thrust Bearing Type TVB on the Internet?
High quality 80tVB347 ( 15.6 kg Mass, ID: 203.2 mm OD: 295.275 mm WD: 76.2 mm , TVB Series , One Rows , PN (ABEC-1) Accuracy Class , bearing steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 80tVB347. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
