803722 Bore 300 Mm, Tapered Roller Thrust Bearings, Double Row For Work Rolls
The 803722 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.
The 803722 bearing is a Tapered Roller Thrust Bearings, double row for work rolls with an inner diameter of 300 mm , an outer diameter of 460 mm, a width of 105 mm. inner ring made of case hardening steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, Its dynamic radial rated load is approximately 915000 N, its static radial rated load is approximately 2000000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
803722 bearings ( 300 mm x 460 mm x 105 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.
| Part Number | 803722 |
| Interchangeable | FAG 803722 |
| Desgin Figure | 2 |
| Cage | Stamping steel cage |
| Arrangement | face-to-face (><) |
| Seal | Open |
| Bearing Type | Tapered Roller Thrust Bearings, double row for work rolls |
| Bearing Weight [lb] | 136.685 |
| d φ Inside [inch] | 11.811 |
| D Φ Outside [inch] | 18.110 |
| B Width [inch] | 4.134 |
| rs min Chamfer Cup | 2 mm |
| r1s min Chamfer Cone | 4 mm |
| Cr Radial Dynamic [lbf] | 205692 |
| C0r Radial Static [lbf] | 449600 |
| Y | 1.17 |
