801999 Bore 380 Mm, Tapered Roller Thrust Bearings, Double Row For Work Rolls
The 801999 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.
The 801999 bearing is a Tapered Roller Thrust Bearings, double row for work rolls with an inner diameter of 380 mm , an outer diameter of 590 mm, a width of 260 mm. inner ring made of case hardening steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, Its dynamic radial rated load is approximately 2900000 N, its static radial rated load is approximately 6800000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
801999 bearings ( 380 mm x 590 mm x 260 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.
| Part Number | 801999 |
| Interchangeable | FAG 801999 |
| Desgin Figure | 3 |
| Cage | Stamping steel cage |
| Arrangement | face-to-face (><) |
| Seal | Open |
| Bearing Type | Tapered Roller Thrust Bearings, double row for work rolls |
| Other | without retaining grooves on the inner ring |
| Bearing Weight [lb] | 540.127 |
| d φ Inside [inch] | 14.961 |
| D Φ Outside [inch] | 23.228 |
| B Width [inch] | 10.236 |
| rs min Chamfer Cup | 3 mm |
| r1s min Chamfer Cone | 2.5 mm |
| Cr Radial Dynamic [lbf] | 651920 |
| C0r Radial Static [lbf] | 1528640 |
| Y | 1.16 |
