7326B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7326B.TVP

Bore Diameter:130 mm

Outside Diameter:280 mm

Width:58 mm

Weight:15.1 kg

Min. Order:1 Piece

The 7326B.TVP

The 7326B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 130 mm , an outer diameter of 280 mm, a width of 58 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 304967 N, its static radial rated load is approximately 324993 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7326-B-TVP,7326B.TVP

Dimensions:

Inside Diameter:

130 mm

Outside Diameter:

280 mm

Thickness:

58 mm

Weight:

15.1 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

304967 N

Static load Capacity, Radial (Cor):

324993 N

Fatigue Load Limit, Radial:

15888 N

Reference speed (Grease rpm):

2590

Limiting speed (Oil rpm):

3029

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

73..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7326B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	73..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7326-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7326-B-TVP,7326B.TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S1 = up to 200°
m Weight [kg]	15.1
Reference From	FAG 7326B.TVP
Dimensions
d φ Inside [inch]	5.118
D Φ Outside [inch]	11.024
B Width [inch]	2.283
r(min.) [inch]	0.157
r₁(min.) [inch]	0.059
D₁ [inch]	8.760
d₁ [inch]	7.421
a [inch]	4.528
Performance
C_r Radial Dynamic [N]	304967
C_0r Radial static [N]	324993
C_ur Radial Fatigue [N]	15888
n_G Limiting speed (oil) [r/min]	3029
n_B Reference speed (grease) [r/min]	2590
Mounting dimensions
d_a(min.) [inch]	5.787
D_a(max.) [inch]	10.354
D_b(max.) [inch]	10.669
r_a(max.) [inch]	0.118
r_a1(max.) [inch]	0.059
