7317B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7317B.TVP

Bore Diameter:85 mm

Outside Diameter:180 mm

Width:41 mm

Weight:4.26 kg

Min. Order:1 Piece

The 7317B.TVP

The 7317B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 85 mm , an outer diameter of 180 mm, a width of 41 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 166992 N, its static radial rated load is approximately 137973 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7317-B-TVP,7317B.TVP

Dimensions:

Inside Diameter:

85 mm

Outside Diameter:

180 mm

Thickness:

41 mm

Weight:

4.26 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

166992 N

Static load Capacity, Radial (Cor):

137973 N

Fatigue Load Limit, Radial:

8287 N

Reference speed (Grease rpm):

4091

Limiting speed (Oil rpm):

4875

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

73..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7317B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	73..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7317-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7317-B-TVP,7317B.TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	4.26
Reference From	FAG 7317B.TVP
Dimensions
d φ Inside [inch]	3.346
D Φ Outside [inch]	7.087
B Width [inch]	1.614
r(min.) [inch]	0.118
r₁(min.) [inch]	0.043
D₁ [inch]	5.675
d₁ [inch]	4.803
a [inch]	2.996
Performance
C_r Radial Dynamic [N]	166992
C_0r Radial static [N]	137973
C_ur Radial Fatigue [N]	8287
n_G Limiting speed (oil) [r/min]	4875
n_B Reference speed (grease) [r/min]	4091
Mounting dimensions
d_a(min.) [inch]	3.898
D_a(max.) [inch]	6.535
D_b(max.) [inch]	6.811
r_a(max.) [inch]	0.098
r_a1(max.) [inch]	0.039
