7314B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7314B.TVP

Bore Diameter:70 mm

Outside Diameter:150 mm

Width:35 mm

Weight:2.555 kg

Min. Order:1 Piece

The 7314B.TVP

The 7314B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 70 mm , an outer diameter of 150 mm, a width of 35 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 125964 N, its static radial rated load is approximately 92985 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7314-B-TVP,7314B.TVP

Dimensions:

Inside Diameter:

70 mm

Outside Diameter:

150 mm

Thickness:

35 mm

Weight:

2.555 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

125964 N

Static load Capacity, Radial (Cor):

92985 N

Fatigue Load Limit, Radial:

6186 N

Reference speed (Grease rpm):

4749

Limiting speed (Oil rpm):

5977

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

73..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7314B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	73..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7314-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7314-B-TVP,7314B.TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	2.555
Reference From	FAG 7314B.TVP
Dimensions
d φ Inside [inch]	2.756
D Φ Outside [inch]	5.905
B Width [inch]	1.378
r(min.) [inch]	0.083
r₁(min.) [inch]	0.043
D₁ [inch]	4.709
d₁ [inch]	4.026
a [inch]	2.508
Performance
C_r Radial Dynamic [N]	125964
C_0r Radial static [N]	92985
C_ur Radial Fatigue [N]	6186
n_G Limiting speed (oil) [r/min]	5977
n_B Reference speed (grease) [r/min]	4749
Mounting dimensions
d_a(min.) [inch]	3.228
D_a(max.) [inch]	5.433
D_b(max.) [inch]	5.630
r_a(max.) [inch]	0.083
r_a1(max.) [inch]	0.039
