7314-B-XL-JP Angular Contact Ball Bearings, Stamping Steel Cage, Single Row

🔍

7314-B-XL-JP

Bore Diameter:70 mm

Outside Diameter:150 mm

Width:35 mm

Weight:2.647 kg

Min. Order:1 Piece

The 7314-B-XL-JP Single-row angular contact ball bearings are widely used in high-speed, high-precision small to medium-sized equipment, such as: machine tool spindles (machining centers, grinding machines), industrial robots (joints), turbochargers, medical equipment (high-speed drills), electric vehicle drive motors, and precision measuring instruments.

The 7314-B-XL-JP bearing is a Angular contact ball bearings, single row with an inner diameter of 70 mm , an outer diameter of 150 mm, a width of 35 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 125993 N, its static radial rated load is approximately 92992 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

70 mm

Outside Diameter:

150 mm

Thickness:

35 mm

Weight:

2.647 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

125993 N

Static load Capacity, Radial (Cor):

92992 N

Fatigue Load Limit, Radial:

6191 N

Reference speed (Grease rpm):

4744

Limiting speed (Oil rpm):

5987

Specifications:

Old Designations:

7314-B-JP

Structure:

Single row angular contact ball bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

JP = Stamping steel cage

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 150 °C

Series:

73..-B-XL-JP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

7314-B-XL-JP bearings ( 70 mm x 150 mm x 35 mm) have the advantages of High speed, high precision, Low friction and low heat generation, and are therefore widely used in the Machine tool spindles, high-speed motors, ball screws, industrial robots, precision instruments, medical equipment, and aerospace components.

Part Number	7314-B-XL-JP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	73..-B-XL-JP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7314-B-JP
Cage	JP = Stamping steel cage
Equivalent	7314-B-JP,7314B.JP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	2.647
Reference From	FAG 7314-B-XL-JP
Dimensions
d φ Inside [inch]	2.756
D Φ Outside [inch]	5.905
B Width [inch]	1.378
r(min.) [inch]	0.083
r₁(min.) [inch]	0.043
D₁ [inch]	4.709
d₁ [inch]	4.026
a [inch]	2.508
Performance
C_r Radial Dynamic [N]	125993
C_0r Radial static [N]	92992
C_ur Radial Fatigue [N]	6191
n_G Limiting speed (oil) [r/min]	5987
n_B Reference speed (grease) [r/min]	4744
Mounting dimensions
d_a(min.) [inch]	3.228
D_a(max.) [inch]	5.433
D_b(max.) [inch]	5.630
r_a(max.) [inch]	0.083
r_a1(max.) [inch]	0.039

The 7314-B-XL-JP Single-row angular contact ball bearings mainly consist of an inner ring, an outer ring, steel balls, and a cage. The raceways of the inner and outer rings are offset from each other to form a contact angle, typically 15°, 25°, or 40°. They feature a non-separable design, and the cage can be made of stamped steel, solid brass, or phenolic resin.

Single-row angular contact ball bearings can simultaneously withstand radial loads and unidirectional axial loads. The larger the contact angle, the stronger the axial load capacity. When installed in pairs (back-to-back, face-to-face, or tandem), they can withstand bidirectional axial loads and significantly improve system rigidity. They possess high-speed, low-friction characteristics, with precision grades ranging from P4 to P2, making them suitable for precision transmissions.
