7204B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7204B.TVP

Bore Diameter:20 mm

Outside Diameter:47 mm

Width:14 mm

Weight:0.103 kg

Min. Order:1 Piece

The 7204B.TVP

The 7204B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 20 mm , an outer diameter of 47 mm, a width of 14 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 14857 N, its static radial rated load is approximately 7763 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7204-B-TVP,7204B.TVP

Dimensions:

Inside Diameter:

20 mm

Outside Diameter:

47 mm

Thickness:

14 mm

Weight:

0.103 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

14857 N

Static load Capacity, Radial (Cor):

7763 N

Fatigue Load Limit, Radial:

537 N

Reference speed (Grease rpm):

15390

Limiting speed (Oil rpm):

21570

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

72..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7204B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	72..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7204-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7204-B-TVP,7204B.TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.103
Reference From	FAG 7204B.TVP
Dimensions
d φ Inside [inch]	0.787
D Φ Outside [inch]	1.850
B Width [inch]	0.551
r(min.) [inch]	0.039
r₁(min.) [inch]	0.024
D₁ [inch]	1.458
d₁ [inch]	1.202
a [inch]	0.831
Performance
C_r Radial Dynamic [N]	14857
C_0r Radial static [N]	7763
C_ur Radial Fatigue [N]	537
n_G Limiting speed (oil) [r/min]	21570
n_B Reference speed (grease) [r/min]	15390
Mounting dimensions
d_a(min.) [inch]	1.008
D_a(max.) [inch]	1.630
D_b(max.) [inch]	1.685
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024
