7203-B-XL-JP Angular Contact Ball Bearings, Stamping Steel Cage, Single Row

🔍

7203-B-XL-JP

Bore Diameter:17 mm

Outside Diameter:40 mm

Width:12 mm

Weight:0.066 kg

Min. Order:1 Piece

The 7203-B-XL-JP Single-row angular contact ball bearings are widely used in high-speed, high-precision small to medium-sized equipment, such as: machine tool spindles (machining centers, grinding machines), industrial robots (joints), turbochargers, medical equipment (high-speed drills), electric vehicle drive motors, and precision measuring instruments.

The 7203-B-XL-JP bearing is a Angular contact ball bearings, single row with an inner diameter of 17 mm , an outer diameter of 40 mm, a width of 12 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 11197 N, its static radial rated load is approximately 5665 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

17 mm

Outside Diameter:

40 mm

Thickness:

12 mm

Weight:

0.066 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

11197 N

Static load Capacity, Radial (Cor):

5665 N

Fatigue Load Limit, Radial:

384 N

Reference speed (Grease rpm):

17090

Limiting speed (Oil rpm):

25976

Specifications:

Old Designations:

7203-B-JP

Structure:

Single row angular contact ball bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

JP = Stamping steel cage

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 150 °C

Series:

72..-B-XL-JP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

7203-B-XL-JP bearings ( 17 mm x 40 mm x 12 mm) have the advantages of High speed, high precision, Low friction and low heat generation, and are therefore widely used in the Machine tool spindles, high-speed motors, ball screws, industrial robots, precision instruments, medical equipment, and aerospace components.

Part Number	7203-B-XL-JP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	72..-B-XL-JP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7203-B-JP
Cage	JP = Stamping steel cage
Equivalent	7203-B-JP,7203B.JP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.066
Reference From	FAG 7203-B-XL-JP
Dimensions
d φ Inside [inch]	0.669
D Φ Outside [inch]	1.575
B Width [inch]	0.472
r(min.) [inch]	0.024
r₁(min.) [inch]	0.012
D₁ [inch]	1.239
d₁ [inch]	1.023
a [inch]	0.709
Performance
C_r Radial Dynamic [N]	11197
C_0r Radial static [N]	5665
C_ur Radial Fatigue [N]	384
n_G Limiting speed (oil) [r/min]	25976
n_B Reference speed (grease) [r/min]	17090
Mounting dimensions
d_a(min.) [inch]	0.835
D_a(max.) [inch]	1.409
D_b(max.) [inch]	1.480
r_a(max.) [inch]	0.024
r_a1(max.) [inch]	0.012

The 7203-B-XL-JP Single-row angular contact ball bearings mainly consist of an inner ring, an outer ring, steel balls, and a cage. The raceways of the inner and outer rings are offset from each other to form a contact angle, typically 15°, 25°, or 40°. They feature a non-separable design, and the cage can be made of stamped steel, solid brass, or phenolic resin.

Single-row angular contact ball bearings can simultaneously withstand radial loads and unidirectional axial loads. The larger the contact angle, the stronger the axial load capacity. When installed in pairs (back-to-back, face-to-face, or tandem), they can withstand bidirectional axial loads and significantly improve system rigidity. They possess high-speed, low-friction characteristics, with precision grades ranging from P4 to P2, making them suitable for precision transmissions.
