7202 Bearing 15x35x11mm

🔍

7202

Bore Diameter:15 mm

Outside Diameter:35 mm

Width:11 mm

Weight:0.045 kg

The 7202 bearing is a Angular contact ball bearings with an inner diameter of 15 mm , an outer diameter of 35 mm, a width of 11 mm. It typically uses P0/P6/P5/P4 grade precision tolerances and Closed type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

15 mm

Outside Diameter:

35 mm

Thickness:

11 mm

Weight:

0.045 KG

Specifications:

Structure:

Inside and outside the circle of

Brand:

ZRB or OEM

Precision Rating:

P0/P6/P5/P4

Bearing Material:

Bakelite

Seals Type:

Closed

Transaction Information:

Payment term:

TT/LC/DP/OA

Delivery time:

10-30 days

Detailed description

7202 Bearing limit rotational speed is higher, can bear radial load and axial load at the same time, can also be subject to pure axial load, its axial load capacity is determined by contact Angle, and with the contact Angle increases. Mainly used for machine tool spindle, high frequency motor, gas turbine, centrifugal separator, small car front wheel and the differential pinion shaft

Model	d	D	B	Cr Cor	Grease Oil	Cr Cor	Grease Oil	Weight
7200	10	30	9	6.4 3.8	55000 84000	6.3 3.7	52000 79000	0.03
7201	12	32	10	7.2 4.5	52000 79000	6.9 4.3	47000 69000	0.036
7202	15	35	11	9.1 5.8	47000 69000	8.8 5.6	42000 62000	0.045
7203	17	42	12	11.3 7.4	39000 59000	10.9 7.1	37000 55000	0.07
7204	20	47	14	13.1 9.6	33000 49000	12.6 9.2	29000 44000	0.11
7205	25	52	15	16.8 13.1	29000 44000	16.1 12.5	25000 39000	0.13
7206	30	62	16	23.4 18.8	23000 37000	22.3 18.0	19000 33000	0.19
7207	35	72	17	25.8 22.9	17000 29000	24.5 21.9	16000 27000	0.28
7208	40	80	18	34.1 30.9	16000 27000	32.5 29.5	14000 23000	0.37
7209	45	85	19	35.5 33.8	15000 25000	33.8 32.3	13000 21000	0.42
7210	50	90	20	43.3 40.6	14000 23000	41.3 38.7	13000 21000	0.47
7211	55	100	21	53.6 51.1	13000 21000	51.1 48.8	12000 19000	0.62
7212	60	110	22	55.8 56.2	11000 18000	53.0 53.5	10000 17000	0.78
7213	65	120	23	67.5 69.0	11000 17000	64.2 65.8	8500 15000	1
7214	70	125	24	70.2 74.6	9000 16000	66.6 71.7	8000 14000	1.1
7215	75	130	25	72.7 80.2	8500 15000	68.9 76.3	7500 13000	1.18
7216	80	140	26	86.5 96.5	8000 14000	82.1 91.9	7000 12000	1.43
7217	85	150	28	97.4 107.5	7500 13000	92.5 102.4	6500 11000	1.83
7218	90	160	30	121.9 131.3	7000 12000	115.8 124.6	6000 10000	2.12
7219	95	170	32	128.9 145.1	6500 11000	122.5 138.3	5700 9000	2.68
