7064CTYNSULP4 Angular Contact Ball Bearing

7064CTYNSULP4

Bore Diameter:320 mm

Outside Diameter:480 mm

Width:74 mm

Weight:47.2 kg

The 7064CTYNSULP4 bearing is a Angular Contact Ball Bearing with an inner diameter of 320 mm , an outer diameter of 480 mm, a width of 74 mm. It typically uses P0/P6/P5/P4 grade precision tolerances and Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

320 mm

Outside Diameter:

480 mm

Thickness:

74 mm

Weight:

47.2 KG

Specifications:

Structure:

Angular Contact Ball Bearing

Precision Rating:

P0/P6/P5/P4

Bearing Material:

GCr15SiMn

Seals Type:

Open

Transaction Information:

Payment term:

30% T/T in Advance, the balance 70%TT before shipp

Delivery time:

Bearing model:7064CTYNSULP4 Angular Contact Ball Bearing
Inner Diameter (ID):320 mm
Outer diameter (OD):480 mm
Width/Height: 74 mm
Material:chrome steel(GCR15SiMn)
Number of Row: single row
Seals type: open
Contact Angle:C=15°;AC=25°,A=30°; B=40°
Material: No mark:Steel ball(SUJ2); SN24:Ceramic ball(Si3N4)
Cage structure:
TYN:polyamide resin cage
TR : Phenolic resin cage
Combination of mark:
SU:Universal combination (single row)
DU:Universal combination (double rows)
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
Preloaded mark:
EL: Micro preloaded
L : Light preload
M : Medium preloade
H : Heavy preloaded
Precision grade:
P2 : ISO2;
P4 : ISO4;
P5 : ISO5
P3 : Special grade(Dimensional accuracy:ISO4,Rotation accuracy:ISO2)
p4Y: Special grade

Share this product to:

Let more people see your product

How can you buy 7064CTYNSULP4 Angular Contact Ball Bearing on the Internet?
High quality 7064CTYNSULP4 ( 47.2 kg Mass, ID: 320 mm OD: 480 mm WD: 74 mm , P0/P6/P5/P4 Accuracy Class , GCr15SiMn Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 7064CTYNSULP4. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
