7036-XL-MP-UA Angular Contact Ball Bearings, Single Row, Solid Brass Cage

🔍

7036-XL-MP-UA

Bore Diameter:180 mm

Outside Diameter:280 mm

Width:46 mm

Weight:9.74 kg

Min. Order:1 Piece

The 7036-XL-MP-UA

The 7036-XL-MP-UA bearing is a Angular contact ball bearings, single row with an inner diameter of 180 mm , an outer diameter of 280 mm, a width of 46 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 239993 N, its static radial rated load is approximately 294982 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7036-MP-UA

Dimensions:

Inside Diameter:

180 mm

Outside Diameter:

280 mm

Thickness:

46 mm

Weight:

9.74 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

239993 N

Static load Capacity, Radial (Cor):

294982 N

Fatigue Load Limit, Radial:

13382 N

Reference speed (Grease rpm):

2542

Limiting speed (Oil rpm):

3792

Specifications:

Old Designations:

7036-MP-UA

Structure:

Angular contact ball bearings, super-precision

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

MP = solid brass cage, ball guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 200 °C

Series:

70..-XL-MP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7036-XL-MP-UA
Bearing Type	Angular contact ball bearings, single row
Series	70..-XL-MP
X-Life	XL long life design
Contact angle - α [°]	30
Rows NO.	single
Manufacturer Part Code	7036-MP-UA
Cage	MP = solid brass cage, ball guided
Equivalent	7036-MP-UA
Lubricant	Without
Seal type	Open
Bearing pair	UA = Universal design for mounting in pairs, bearing pair has small axial internal clearance in O and X arrangement
Heat stabilization	S1 = up to 200°
m Weight [kg]	9.74
Reference From	FAG 7036-XL-MP-UA
Dimensions
d φ Inside [inch]	7.087
D Φ Outside [inch]	11.024
B Width [inch]	1.811
r(min.) [inch]	0.083
r₁(min.) [inch]	0.043
D₁ [inch]	9.612
d₁ [inch]	8.583
a [inch]	3.520
Performance
C_r Radial Dynamic [N]	239993
C_0r Radial static [N]	294982
C_ur Radial Fatigue [N]	13382
n_G Limiting speed (oil) [r/min]	3792
n_B Reference speed (grease) [r/min]	2542
Mounting dimensions
d_a(min.) [inch]	7.488
D_a(max.) [inch]	10.622
D_b(max.) [inch]	10.787
r_a(max.) [inch]	0.083
r_a1(max.) [inch]	0.039
Axial clearance
Axial clearance per set - A_min [µm]	76
Tolerance for axial clearance or preload per set - Tol(+) [µm]	12
