7032MP Angular Contact Ball Bearings, Single Row, Solid Brass Cage

🔍

7032MP

Bore Diameter:160 mm

Outside Diameter:240 mm

Width:38 mm

Weight:6.48 kg

Min. Order:1 Piece

The 7032MP

The 7032MP bearing is a Angular contact ball bearings, single row with an inner diameter of 160 mm , an outer diameter of 240 mm, a width of 38 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 159955 N, its static radial rated load is approximately 199959 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

160 mm

Outside Diameter:

240 mm

Thickness:

38 mm

Weight:

6.48 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

159955 N

Static load Capacity, Radial (Cor):

199959 N

Fatigue Load Limit, Radial:

7389 N

Reference speed (Grease rpm):

2941

Limiting speed (Oil rpm):

4094

Specifications:

Structure:

Angular contact ball bearings, super-precision

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

MP = solid brass cage, ball guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 150 °C

Series:

70..-MP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7032MP
Bearing Type	Angular contact ball bearings, single row
Series	70..-MP
Contact angle - α [°]	30
Rows NO.	single
Manufacturer Part Code	7032-MP
Cage	MP = solid brass cage, ball guided
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	6.48
Reference From	FAG 7032MP
Dimensions
d φ Inside [inch]	6.299
D Φ Outside [inch]	9.449
B Width [inch]	1.496
r(min.) [inch]	0.083
r₁(min.) [inch]	0.043
D₁ [inch]	8.189
d₁ [inch]	7.575
a [inch]	3.020
Performance
C_r Radial Dynamic [N]	159955
C_0r Radial static [N]	199959
C_ur Radial Fatigue [N]	7389
n_G Limiting speed (oil) [r/min]	4094
n_B Reference speed (grease) [r/min]	2941
Mounting dimensions
d_a(min.) [inch]	6.701
D_a(max.) [inch]	9.047
D_b(max.) [inch]	9.213
r_a(max.) [inch]	0.083
r_a1(max.) [inch]	0.039
