7026-XL-MP-UA Angular Contact Ball Bearings, Single Row, Solid Brass Cage

🔍

7026-XL-MP-UA

Bore Diameter:130 mm

Outside Diameter:200 mm

Width:33 mm

Weight:3.64 kg

Min. Order:1 Piece

The 7026-XL-MP-UA

The 7026-XL-MP-UA bearing is a Angular contact ball bearings, single row with an inner diameter of 130 mm , an outer diameter of 200 mm, a width of 33 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 130971 N, its static radial rated load is approximately 141960 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7026-MP-UA

Dimensions:

Inside Diameter:

130 mm

Outside Diameter:

200 mm

Thickness:

33 mm

Weight:

3.64 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

130971 N

Static load Capacity, Radial (Cor):

141960 N

Fatigue Load Limit, Radial:

7682 N

Reference speed (Grease rpm):

3444

Limiting speed (Oil rpm):

5471

Specifications:

Old Designations:

7026-MP-UA

Structure:

Angular contact ball bearings, super-precision

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

MP = solid brass cage, ball guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 150 °C

Series:

70..-XL-MP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7026-XL-MP-UA
Bearing Type	Angular contact ball bearings, single row
Series	70..-XL-MP
X-Life	XL long life design
Contact angle - α [°]	30
Rows NO.	single
Manufacturer Part Code	7026-MP-UA
Cage	MP = solid brass cage, ball guided
Equivalent	7026-MP-UA
Lubricant	Without
Seal type	Open
Bearing pair	UA = Universal design for mounting in pairs, bearing pair has small axial internal clearance in O and X arrangement
Heat stabilization	S0 = up to 150°
m Weight [kg]	3.64
Reference From	FAG 7026-XL-MP-UA
Dimensions
d φ Inside [inch]	5.118
D Φ Outside [inch]	7.874
B Width [inch]	1.299
r(min.) [inch]	0.079
r₁(min.) [inch]	0.039
D₁ [inch]	6.770
d₁ [inch]	6.220
a [inch]	2.524
Performance
C_r Radial Dynamic [N]	130971
C_0r Radial static [N]	141960
C_ur Radial Fatigue [N]	7682
n_G Limiting speed (oil) [r/min]	5471
n_B Reference speed (grease) [r/min]	3444
Mounting dimensions
d_a(min.) [inch]	5.465
D_a(max.) [inch]	7.528
D_b(max.) [inch]	7.693
r_a(max.) [inch]	0.079
r_a1(max.) [inch]	0.039
Axial clearance
Axial clearance per set - A_min [µm]	60
Tolerance for axial clearance or preload per set - Tol(+) [µm]	12
