685-672 High Speed Tapered Roller Bearings

🔍

685-672

Bore Diameter:98.425 mm

Outside Diameter:168.275 mm

Width:41.275 mm

Min. Order:2 Piece

The 685-672 bearing is a Tapered Roller Bearings with an inner diameter of 98.425 mm , an outer diameter of 168.275 mm, a width of 41.275 mm. It typically uses p0/p6/p5/p4/p2 grade precision tolerances and features a Steel cage, Steel balls, steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 435000, It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Reducer, Papermaking Machinery, Railway Vehicle

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

98.425 mm

Outside Diameter:

168.275 mm

Thickness:

41.275 mm

Cone Width (B):

41.275

Cup Width (C):

30.163

Performance Data:

Dynamic load Capacity, Radial (Cr):

435000

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Demensions:

98.425*168.275*41.275

Brand:

Z&K/Neutral / OEM

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Precision Rating:

p0/p6/p5/p4/p2

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Bearing Material:

Bearing Steel

Cage material:

Steel

Ball Material:

Steel

Roller Material:

steel

Series:

675

Cone Number:

685

Cup Number:

672

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

10 Piece

Production Capacity:

1000PCS/Year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

685-672 High Speed Tapered Roller Bearings
685-672 High Speed Tapered Roller Bearings
Bearing NO.:	685-672	MOQ:	1PCS
Series:	675	Material	Bearing steel
Cone Part NO.:	685	Aa (mm):	4.3
Cup Part NO.:	672	Ab (mm):	3
Bore (mm)b:	98.425	Db (mm):	149.1
Cup Outer Diameter(mm)D:	168.275	db(mm):	116
Cone Width(mm)B:	41.275	Da(mm):	161
Cup Width(mm)C:	30.163	da (mm):	109
Bearing Width (mm)T:	41.275	r (mm):	3.3
Cg:	0.106	R(mm):	3.6
Dynamic load rating (C₉₀)N:	68600	K:	1.24
Dynamic load rating (C₁)N:	265000	e :	0.47
Static Radial Rating (CO)N:	386000	Y :	1.28
Dynamic Thrust Ratin(Ca₉₀)N:	55300	a:	-2.8
Applicable Industries:	Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company	Contact Bonnie:	Email:[email protected]
Applicable Industries:		Contact Bonnie:	Email:[email protected]

Share this product to:

Let more people see your product

How can you buy 685-672 High Speed Tapered Roller Bearings on the Internet?
High quality 685-672 ( ID: 98.425 mm OD: 168.275 mm WD: 41.275 mm , 675 Series , C0 C2 C3 C4 C5 Radial Clearance , p0/p6/p5/p4/p2 Accuracy Class , Bearing Steel Material , 435000 Radial dynamic ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 685-672. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
