6323M Deep Groove Ball Bearing (Alt P/N: 115BC03)
The 6323M bearing is a Deep Groove Ball Bearings with an inner diameter of 115 mm , an outer diameter of 250 mm, a width of 53 mm. It typically uses Standard grade precision tolerances and features a Steel cage, Chrome Steel (Gcr15) balls, It primarily bears Radial & Axial, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Equivalent: 115BC03
Application: Electric motors and generators, Agriculture, Material handlin, Industrial transmissions, Food and beverage, Industrial pumps, Industrial fans, Two and three wheelers, Cars, light trucks, and etc.
6323M Deep Groove Ball Bearing (Interchange Part No.: 115BC03), Single Row, Open Type, Low Friction, Low Noise, Low Vibration, and High Running Speeds.
Size: 115x250x53mm
Inside Diameter (d): 115mm
Outside Diameter (D): 250mm
Width (B): 53mm
Race Material: GCR15 Bearing Steel
Ball Material: GCR15 Bearing Steel
Cage Material: Steel
Encloser: Open
Number of Row: Single
Bore Type: Cylindrical
Working Temperature: -30°C to 120°C
Loading Direction: Radial and Axial
Radial Internal Clearance: Normal
Tolerance Class: Normal
HS Code: 8482102000
|
Deep Groove Ball Bearing |
|||||
|
Part No. |
Dimensions (mm) |
Weight |
Interchange Part No. |
||
|
d |
D |
B |
Lbs |
Torrington |
|
|
6323M |
115 |
250 |
53 |
26.5 |
115BC03 |
Deep groove ball bearings are the most widely used bearing type and are particularly versatile. They have low friction and are optimized for low noise and low vibration which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than other bearing types.
Applications: Electric motors and generators, Agriculture, Material handlin, Industrial transmissions, Food and beverage, Industrial pumps, Industrial fans, Two and three wheelers, Cars, light trucks, and etc.
All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected] or contact us by Wechat or Whatsapp at +8618062246726.
