6320 Deep Groove Ball Bearings Open Design, Self-retaining

🔍

6320

Bore Diameter:100 mm

Outside Diameter:215 mm

Width:47 mm

Weight:7.394 kg

Min. Order:1 Piece

The 6320

The 6320 bearing is a Deep groove ball bearings open design, self-retaining with an inner diameter of 100 mm , an outer diameter of 215 mm, a width of 47 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, Its dynamic radial rated load is approximately 176909 N, its static radial rated load is approximately 136914 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: RHP 6320 , STEYR 6320 , TORRINGTON,FAFNIR 320K , NSK 6320 , NACHI 6320 , NTN 6320 , KOYO 6320 , FAG 6320 , SKF 6320 , MRC 320S , SNR 6320 ,

Dimensions:

Inside Diameter:

100 mm

Outside Diameter:

215 mm

Thickness:

47 mm

Weight:

7.394 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

176909 N

Static load Capacity, Radial (Cor):

136914 N

Fatigue Load Limit, Radial:

7377 N

Reference speed (Grease rpm):

4571

Limiting speed (Oil rpm):

4215

Specifications:

Old Designations:

320

Structure:

Single row deep groove ball bearings

Number of Rows:

one

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

JN = Stamping steel cage

Seals Type:

Open

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 150 °C

Series:

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	6320
Reference From	FAG 6320
Bearing Type	Deep groove ball bearings open design, self-retaining
Series	63
Sealing	Open
Cage	JN = Stamping steel cage
Radial internal clearances	CN
Heat stabilization	S0 = (up to 150 °C)
Lubricant	Without
Weight [lb]	16.301
C_r Radial Dynamic [lbf]	39769
C_0r Radial static [lbf]	30778
C_ur Radial Fatigue [lbf]	1658
n_B Reference speed [rpm]	4571
n_G Limiting speed [rpm]	4215
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	150
d φ Inside [inch]	3.937
D Φ Outside [inch]	8.465
B Width [inch]	1.850
r(min.) [inch]	0.118
D₁ [inch]	7.053
d₁ [inch]	5.453
Mounting dimensions
d_a(min.) [inch]	4.488
D_a(max.) [inch]	7.913
r_a(max.) [inch]	0.098
Coefficient - F₀ [inch]	13.7

Share this product to:

Let more people see your product

How can you buy 6320 Deep Groove Ball Bearings Open Design, Self-retaining on the Internet?
High quality 6320 ( 7.394 kg Mass, ID: 100 mm OD: 215 mm WD: 47 mm , 63 Series , one Rows , CN Radial Clearance , PN Accuracy Class , GCr15SiMn Material , 176909 Radial dynamic , 136914 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 6320. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
