6310 Deep Groove Ball Bearings Open Design, Self-retaining

🔍

6310

Bore Diameter:50 mm

Outside Diameter:110 mm

Width:27 mm

Weight:1.049 kg

Min. Order:1 Piece

The 6310

The 6310 bearing is a Deep groove ball bearings open design, self-retaining with an inner diameter of 50 mm , an outer diameter of 110 mm, a width of 27 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, Its dynamic radial rated load is approximately 67917 N, its static radial rated load is approximately 38407 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: RHP 6310 , FAG 6310 , NTN 6310 , KOYO 6310 , NACHI 6310 , SKF 6310 , NSK 6310 , STEYR 6310 , SNR 6310 , MRC 310S , TORRINGTON,FAFNIR 310K ,

Dimensions:

Inside Diameter:

50 mm

Outside Diameter:

110 mm

Thickness:

27 mm

Weight:

1.049 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

67917 N

Static load Capacity, Radial (Cor):

38407 N

Fatigue Load Limit, Radial:

2627 N

Reference speed (Grease rpm):

7671

Limiting speed (Oil rpm):

9462

Specifications:

Old Designations:

310

Structure:

Single row deep groove ball bearings

Number of Rows:

one

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

JN = Stamping steel cage

Seals Type:

Open

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 150 °C

Series:

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	6310
Reference From	FAG 6310
Bearing Type	Deep groove ball bearings open design, self-retaining
Series	63
Sealing	Open
Cage	JN = Stamping steel cage
Radial internal clearances	CN
Heat stabilization	S0 = (up to 150 °C)
Lubricant	Without
Weight [lb]	2.313
C_r Radial Dynamic [lbf]	15267
C_0r Radial static [lbf]	8633
C_ur Radial Fatigue [lbf]	590
n_B Reference speed [rpm]	7671
n_G Limiting speed [rpm]	9462
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	150
d φ Inside [inch]	1.969
D Φ Outside [inch]	4.331
B Width [inch]	1.063
D₂ [inch]	3.744
r(min.) [inch]	0.079
D₁ [inch]	3.615
d₁ [inch]	2.677
Mounting dimensions
d_a(min.) [inch]	2.402
D_a(max.) [inch]	3.898
r_a(max.) [inch]	0.079
Coefficient - F₀ [inch]	13.3

Share this product to:

Let more people see your product

How can you buy 6310 Deep Groove Ball Bearings Open Design, Self-retaining on the Internet?
High quality 6310 ( 1.049 kg Mass, ID: 50 mm OD: 110 mm WD: 27 mm , 63 Series , one Rows , CN Radial Clearance , PN Accuracy Class , GCr15SiMn Material , 67917 Radial dynamic , 38407 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 6310. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
