61911 Deep Groove Ball Bearings Open Design, Self-retaining

🔍

61911

Bore Diameter:55 mm

Outside Diameter:80 mm

Width:13 mm

Weight:0.18 kg

Min. Order:1 Piece

The 61911 Single-row deep groove ball bearings are widely used in various rotating machinery, such as: electric motors (general-purpose motors, household appliances), automotive wheel hubs, industrial gearboxes, agricultural machinery, pumps and compressors, conveying equipment, and power tools.

The 61911 bearing is a Deep groove ball bearings open design, self-retaining with an inner diameter of 55 mm , an outer diameter of 80 mm, a width of 13 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, Its dynamic radial rated load is approximately 17619 N, its static radial rated load is approximately 14027 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: NSK 6911 , KOYO 6911 , NTN 6911 , SKF 61911 , FAG 61911 , NACHI 6911 , MRC 1911S , TORRINGTON,FAFNIR 9311K ,

Dimensions:

Inside Diameter:

55 mm

Outside Diameter:

80 mm

Thickness:

13 mm

Weight:

0.18 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

17619 N

Static load Capacity, Radial (Cor):

14027 N

Fatigue Load Limit, Radial:

752 N

Reference speed (Grease rpm):

7466

Limiting speed (Oil rpm):

12066

Specifications:

Old Designations:

1000911

Structure:

Thin section deep groove ball bearings

Number of Rows:

one

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

JN = Stamping steel cage

Seals Type:

Open

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 120 °C

Series:

619

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

61911 bearings ( 55 mm x 80 mm x 13 mm) have the advantages of simple structure, ability to withstand radial and bidirectional axial loads, low friction, and high speed, it is suitable for high-speed, low-noise applications, and are therefore widely used in the Motors, home appliances, automobiles, pumps, compressors, conveying equipment and general industrial machinery.

Part Number	61911
Reference From	FAG 61911
Bearing Type	Deep groove ball bearings open design, self-retaining
Series	619
Sealing	Open
Cage	JN = Stamping steel cage
Radial internal clearances	CN
Heat stabilization	SN = (up to 120 °C)
Lubricant	Without
Weight [lb]	0.397
C_r Radial Dynamic [lbf]	3960
C_0r Radial static [lbf]	3153
C_ur Radial Fatigue [lbf]	169
n_B Reference speed [rpm]	7466
n_G Limiting speed [rpm]	12066
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	120
d φ Inside [inch]	2.165
D Φ Outside [inch]	3.150
B Width [inch]	0.512
D₂ [inch]	2.921
r(min.) [inch]	0.039
D₁ [inch]	2.827
d₁ [inch]	2.488
Mounting dimensions
d_a(min.) [inch]	2.346
D_a(max.) [inch]	2.968
r_a(max.) [inch]	0.039
Coefficient - F₀ [inch]	16.3

The 61911 Single-row deep groove ball bearings mainly consist of an inner ring, outer ring, steel balls, and a cage. The raceways are deep grooves, with the steel balls making four-point contact with the raceways. The inner and outer rings can be separable or integrated. They are available in various forms, including open, with dust covers, and with seals.

Single-row deep groove ball bearings have a simple structure and are the most widely used. They can simultaneously withstand radial loads and bidirectional axial loads, making them suitable for high-speed operation. They have a low coefficient of friction, low noise, and are easy to install and maintain. Versions with seals or dust covers effectively prevent contaminant intrusion and are suitable for various operating conditions.
