6018M Bearing 90x140x24mm

🔍

6018M

Bore Diameter:90 mm

Outside Diameter:140 mm

Width:24 mm

Weight:1.10 kg

The 6018M bearing is a Deep Groove Ball Bearings with an inner diameter of 90 mm , an outer diameter of 140 mm, a width of 24 mm. It typically uses P6 grade precision tolerances and open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

90 mm

Outside Diameter:

140 mm

Thickness:

24 mm

Weight:

1.10 KG

Specifications:

Structure:

deep groove ball bearing

Brand:

ESG

Precision Rating:

Bearing Material:

chorome steel

Seals Type:

open

Transaction Information:

Payment term:

T/T, L/C

Delivery time:

10 days if in stock, within 45 days if no stock

Detailed description

Bearing Code: 6018M

Bearing Type: deep groove ball bearing

Application: used in rolling mills for the rolled products.

Boundary dimensions(mm)				Basic load ratings(kN)		Speed rating		Designations	Weight
Boundary dimensions(mm)				Basic load ratings(kN)		(rpm)			(kg)
d	D	B	rmin	Cr	Cor	Grease	Oil
90	140	24	1.5	40.3	42.5	3900	5200	6018M	1.1

More sizes for your choice:

Boundary dimensions(mm) Speed rating Designations

(rpm)

d D B rmin Cr Cor Grease Oil

90 140 24 1.5 40.3 42.5 3900 5200 6018M

95 145 24 1.5 42.3 46.5 3700 4900 6019M

100 140 20 1.1 30.9 37.8 3700 4900 61920M

100 150 24 1.5 44.2 50.6 3500 4700 6020M

110 150 20 1.1 31.6 40.3 3400 4500 61922M

110 170 28 2 55 62.5 3100 4100 6022M

120 165 22 1.1 39.2 50.9 3000 4000 61924M

120 180 28 2 57.1 68.2 2900 3800 6024M

130 180 24 1.5 48.2 63.5 2800 3700 61926M

130 200 33 2 74.3 87.2 2600 3400 6026M

140 190 24 1.5 51 71 2600 3400 61928M

140 210 33 2 80.9 102 2400 3200 6028M

150 210 28 2 62.7 85.2 2300 3100 61930M

150 225 35 2.1 85 110 2200 2900 6030M

150 230 35 2.1 85 110 2200 2900 6030X1M

155 215 28 2 62.4 85.3 2300 3000 61931M

160 220 28 2 64.5 90.5 2200 2900 61932M

160 240 38 2.1 85.8 118 2000 2700 6032M

170 230 28 2 68 100 2000 2700 61934M

170 260 42 2.1 97 137 1900 2500 6034M

170 265 42 2.1 97 37 1900 2500 6034X2-1M

170 270 42 2.1 97 137 1800 2400 6034X2-2M

180 250 33 2 84.6 119 1900 2500 61936M

180 259.5 33 2 90 130 1800 2400 63196X2M

180 259.5 52 2 98 137 1800 2400 63936X1M

180 260 42 2 98 137 1800 2400 62936X2M

180 280 46 2.1 134 180 1700 2300 6036M

190 240 24 1.5 54.6 84.2 1900 2500 61838M

190 260 33 2 90 133 1800 2400 61938M

190 269.5 33 2 90 133 1700 2300 61938X1M

190 290 46 2.1 144 200 1600 2200 6038M

200 250 24 1.5 55.5 87.6 1800 2400 61840M

200 279.5 38 2.1 110 180 1600 2200 61940X1-1M

200 280 38 2.1 110 158 1600 2200 61940M

200 289.5 38 2.1 110 158 1600 2200 61940X1-2M

200 310 51 2.1 159 225 1500 2000 6040M

220 270 24 1.5 57.3 94.2 1600 2200 61844M

220 300 38 2.1 105 162 1500 2000 61944M

220 300 60 2.1 105 162 1500 2000 63944M

220 309.5 38 3 116 178 1450 1930 61944X1M

220 340 56 3 172 265 1350 1800 6044M

230 329.5 40 3 1389 215 1350 1800 61946X3M

240 300 28 2 73.6 122 1400 1860 61848M

240 320 38 2.1 119 186 1350 1800 61948M

240 359.5 56 3 177 286 1230 1640 6048X1M

240 360 56 3 177 286 1230 1640 6048M

250 359.5 46 2.1 157 254 1200 1600 61950X1M

260 320 28 2 76 131 1300 1720 61852M

260 360 46 2.1 163 269 1180 1570 61952M

260 369.5 46 2.1 163 269 1150 1530 61952X1-2M

260 369.5 60 2.1 163 269 1150 1530 62952X1-1M

260 370 46 2.1 163 269 1150 1530 61952X1-1M

260 374.5 60 2.1 163 269 1140 1520 62952X1-2M

260 400 65 4 224 376 1080 1440 6052M

280 350 33 2 99.8 170 1150 1530 61856M

280 375 65 2.1 167 285 1100 1460 62956X3-1M

280 380 46 2.1 168 285 1080 1440 61956M

280 389.5 46 2.1 167 285 1060 1420 61956X1-2M

280 389.5 65 3 181 310 1060 1420 62956X3-2M

280 390 46 2.1 167 285 1060 1420 61956X1-1M

280 420 65 4 232 407 1000 1340 6056M

300 380 38 2.1 114 198 1040 1390 61860M

300 419.5 56 3 198 349 960 1290 61960X1M

300 420 56 3 198 349 960 1290 61960M

300 459.5 74 1 257 473 900 1220 6060X1M

300 460 74 4 257 473 900 1220 6060M

320 400 38 2.1 115 205 960 1290 61864M

320 440 56 3 212 394 900 1220 61964M

320 459.5 70 4 237 442 880 1170 62964X3M

320 480 74 4 269 509 850 1130 6064M

340 420 38 2.1 119 219 900 1220 61868M

340 460 56 3 118 418 850 1130 61968M

340 520 82 5 310 596 800 1050 6068M

360 440 38 2.1 120 226 850 1130 61872M

360 480 56 3 223 438 820 1080 61972M

360 540 82 5 324 649 760 1000 6072M

380 480 46 2.1 178 337 800 1050 61876M

380 520 65 4 250 505 760 1000 61976M

380 560 82 5 336 699 720 950 6076M

400 500 46 2.1 181 350 760 1000 61880M

400 540 65 4 256 533 720 950 61980M

400 600 90 5 361 751 670 880 6080M

420 520 46 2.1 183 363 720 950 61884M

420 560 65 4 262 558 690 900 61984M

420 620 90 5 376 814 630 830 6084M
