6007ZR Deep Groove Ball Bearings Z Design

🔍

6007ZR

Bore Diameter:35 mm

Outside Diameter:62 mm

Width:14 mm

Weight:0.148 kg

Min. Order:1 Piece

The 6007ZR Single-row deep groove ball bearings are widely used in various rotating machinery, such as: electric motors (general-purpose motors, household appliances), automotive wheel hubs, industrial gearboxes, agricultural machinery, pumps and compressors, conveying equipment, and power tools.

The 6007ZR bearing is a Deep groove ball bearings Z design with an inner diameter of 35 mm , an outer diameter of 62 mm, a width of 14 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, Its dynamic radial rated load is approximately 16915 N, its static radial rated load is approximately 10212 N. It uses CN standard radial clearance, Z = Gap seal on one side type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 6007Z,6007ZR

Dimensions:

Inside Diameter:

35 mm

Outside Diameter:

62 mm

Thickness:

14 mm

Weight:

0.148 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

16915 N

Static load Capacity, Radial (Cor):

10212 N

Fatigue Load Limit, Radial:

537 N

Reference speed (Grease rpm):

11666

Limiting speed (Oil rpm):

16068

Specifications:

Old Designations:

6007Z

Structure:

Single row deep groove ball bearings

Number of Rows:

one

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

JN = Stamping steel cage

Seals Type:

Z = Gap seal on one side

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 120 °C

Series:

60..-Z

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

6007ZR bearings ( 35 mm x 62 mm x 14 mm) have the advantages of simple structure, ability to withstand radial and bidirectional axial loads, low friction, and high speed, it is suitable for high-speed, low-noise applications, and are therefore widely used in the Motors, home appliances, automobiles, pumps, compressors, conveying equipment and general industrial machinery.

Part Number	6007ZR
Reference From	FAG 6007ZR
Bearing Type	Deep groove ball bearings Z design
Series	60..-Z
Sealing	Z = Gap seal on one side
Cage	JN = Stamping steel cage
Radial internal clearances	CN
Heat stabilization	SN = (up to 120 °C)
Lubricant	Without
Equivalent	6007Z , 6007ZR
Weight [lb]	0.326
C_r Radial Dynamic [lbf]	3802
C_0r Radial static [lbf]	2295
C_ur Radial Fatigue [lbf]	120
n_B Reference speed [rpm]	11666
n_G Limiting speed [rpm]	16068
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	120
d φ Inside [inch]	1.378
D Φ Outside [inch]	2.441
B Width [inch]	0.551
D₂ [inch]	2.181
r(min.) [inch]	0.039
D₁ [inch]	2.091
d₁ [inch]	1.701
Mounting dimensions
d_a(min.) [inch]	1.559
D_a(max.) [inch]	2.260
r_a(max.) [inch]	0.039
Coefficient - F₀ [inch]	14.9

The 6007ZR Single-row deep groove ball bearings mainly consist of an inner ring, outer ring, steel balls, and a cage. The raceways are deep grooves, with the steel balls making four-point contact with the raceways. The inner and outer rings can be separable or integrated. They are available in various forms, including open, with dust covers, and with seals.

Single-row deep groove ball bearings have a simple structure and are the most widely used. They can simultaneously withstand radial loads and bidirectional axial loads, making them suitable for high-speed operation. They have a low coefficient of friction, low noise, and are easy to install and maintain. Versions with seals or dust covers effectively prevent contaminant intrusion and are suitable for various operating conditions.

Share this product to:

Let more people see your product

How can you buy 6007ZR Deep Groove Ball Bearings Z Design on the Internet?
High quality 6007ZR ( 0.148 kg Mass, ID: 35 mm OD: 62 mm WD: 14 mm , 60..-Z Series , one Rows , CN Radial Clearance , PN Accuracy Class , GCr15SiMn Material , 16915 Radial dynamic , 10212 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 6007ZR. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
