6002H Deep Groove Ball Bearings Open Design, Self-retaining

🔍

6002H

Bore Diameter:15 mm

Outside Diameter:32 mm

Width:9 mm

Weight:0.031 kg

Min. Order:1 Piece

The 6002H Stainless steel deep groove ball bearings are widely used in fields with stringent requirements for corrosion resistance and cleanliness, such as: food processing equipment (mixers, filling machines), medical devices (surgical instruments, dental handpieces), chemical pumps, marine engineering (ship equipment), pharmaceutical machinery, and semiconductor equipment (cleaning devices).

The 6002H bearing is a Deep groove ball bearings open design, self-retaining with an inner diameter of 15 mm , an outer diameter of 32 mm, a width of 9 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, Its dynamic radial rated load is approximately 5815 N, its static radial rated load is approximately 2815 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

15 mm

Outside Diameter:

32 mm

Thickness:

9 mm

Weight:

0.031 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

5815 N

Static load Capacity, Radial (Cor):

2815 N

Fatigue Load Limit, Radial:

126 N

Reference speed (Grease rpm):

21442

Limiting speed (Oil rpm):

33455

Specifications:

Structure:

Stainless steel deep groove ball bearings

Number of Rows:

one

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

JN = Stamping steel cage

Seals Type:

Open

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 120 °C

Series:

60..-H

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

6002H bearings ( 15 mm x 32 mm x 9 mm) have the advantages of Corrosion resistant, high and low temperature resistant, clean and hygienic, and maintenance-free., and are therefore widely used in the Food processing equipment, medical equipment, chemical equipment, ships, outdoor equipment, and semiconductor manufacturing.

Part Number	6002H
Reference From	FAG 6002H
Bearing Type	Deep groove ball bearings open design, self-retaining
Series	60..-H
Internal design	H = H-Series
Sealing	Open
Cage	JN = Stamping steel cage
Radial internal clearances	CN
Heat stabilization	SN = (up to 120 °C)
Lubricant	Without
Weight [lb]	0.068
C_r Radial Dynamic [lbf]	1307
C_0r Radial static [lbf]	632
C_ur Radial Fatigue [lbf]	28
n_B Reference speed [rpm]	21442
n_G Limiting speed [rpm]	33455
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	120
d φ Inside [inch]	0.591
D Φ Outside [inch]	1.260
B Width [inch]	0.354
r(min.) [inch]	0.012
D₁ [inch]	1.047
d₁ [inch]	0.803
Mounting dimensions
d_a(min.) [inch]	0.669
D_a(max.) [inch]	1.181
r_a(max.) [inch]	0.012
Coefficient - F₀ [inch]	14

The 6002H Stainless steel deep groove ball bearings are primarily composed of inner and outer rings made of martensitic stainless steel (such as 440C) or austenitic stainless steel (such as 304, 316), stainless steel balls, and a cage (made of stamped stainless steel or PTFE). They are available in various forms, including open type, with stainless steel dust covers, or rubber seals.

Stainless steel deep groove ball bearings offer excellent corrosion resistance, allowing for long-term operation without rusting in humid, acidic, alkaline, and saltwater environments. They are clean and hygienic, meeting the standards of the food and medical industries. Austenitic stainless steel has non-magnetic properties, making it suitable for precision instruments. The cage can be made of PTFE or self-lubricating materials, enabling lubrication-free operation.

Share this product to:

Let more people see your product

How can you buy 6002H Deep Groove Ball Bearings Open Design, Self-retaining on the Internet?
High quality 6002H ( 0.031 kg Mass, ID: 15 mm OD: 32 mm WD: 9 mm , 60..-H Series , one Rows , CN Radial Clearance , PN Accuracy Class , GCr15SiMn Material , 5815 Radial dynamic , 2815 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 6002H. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
