540tVL720 Single-row Angular Contact Thrust Ball Bearing

🔍

540tVL720

Bore Diameter:1371.6 mm

Outside Diameter:1619.25 mm

Width:139.7 mm

Weight:480.3 kg

Min. Order:1 Piece

The 540tVL720 Thrust angular contact ball bearings are mainly suitable for applications requiring high speed, low friction, and simultaneous axial and certain radial loads, such as fluid control valves, machine tool worktables and spindles, and rotary tables in the oil and gas drilling industry.

The 540tVL720 bearing is a Single-row angular contact thrust ball bearing with an inner diameter of 1371.6 mm , an outer diameter of 1619.25 mm, a width of 139.7 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic axial rated load is approximately 1468915 N, its static axial rated load is approximately 13873526 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

1371.6 mm

Outside Diameter:

1619.25 mm

Thickness:

139.7 mm

Weight:

480.3 KG

Dynamic load Capacity, axial:

1468915 N

Static load Capacity, axial:

13873526 N

Specifications:

Structure:

Thrust Angular Contact Ball Bearings

Number of Rows:

One

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Metric

Series:

TVL

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

540tVL720 bearings ( 1371.6 mm x 1619.25 mm x 139.7 mm) have the advantages of Composite load, high speed, high rigidity, and are therefore widely used in the rotary tables of oil and gas drilling rigs.

Part Number	540tVL720
Design type	TVL: Single-row angular contact construction
Bearing Type	Single-row angular contact thrust ball bearing
Interchangeable	TIMKEN 540tVL720
Manufacturer Part Code	540 TVL 720
Series	TVL
Units	Metric
Tolerance class	PN (ABEC-1)
C_0a Axial Static [lbf]	3118768
C_a Axial Dynamic [lbf]	330212
d φ Inside [inch]	53.9999
D Φ Outside [inch]	63.7499
T Width [inch]	5.5000
r Fillet Radius [inch]	0.2520
d₁ [inch]	57.3747
D₁ [inch]	60.3747
E (Max) Shoulder Diameter Housing [inch]	58.8739
H (Min) Shoulder Diameter Shaft [inch]	58.8739
Dowel Pin (Pin Dia.) [inch]	0.8740
Hole Location (Small Bore Ring) [inch]	28.1259
Hole Location (Large Bore Ring) [inch]	30.7480
Weight [lb]	1058.8694

The 540tVL720 Thrust angular contact ball bearings are mainly composed of precision-ground steel balls, hardened and ground steel raceways, and a brass (or bronze) cage. Their core characteristic is their ability to simultaneously withstand axial thrust loads and a certain amount of radial load, and they also feature low friction, quiet operation, and suitability for high-speed operation.

Share this product to:

Let more people see your product

How can you buy 540tVL720 Single-row Angular Contact Thrust Ball Bearing on the Internet?
High quality 540tVL720 ( 480.3 kg Mass, ID: 1371.6 mm OD: 1619.25 mm WD: 139.7 mm , TVL Series , One Rows , PN (ABEC-1) Accuracy Class , bearing steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 540tVL720. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.

540tVL720 Single-row Angular Contact Thrust Ball Bearing
