537406 Bore 160 Mm, Angular Contact Ball Bearings, Double Row For Wire Mills, Machined Brass Cage

🔍

537406

Bore Diameter:160 mm

Outside Diameter:239.5 mm

Width:76 mm

Weight:11.4 kg

Min. Order:1 Piece

The 537406 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.

The 537406 bearing is a Angular Contact Ball Bearings, double row non-separable Thrust bearings for wire mills with an inner diameter of 160 mm , an outer diameter of 239.5 mm, a width of 76 mm. Bearing steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, Its dynamic radial rated load is approximately 232000 N, its static radial rated load is approximately 325000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

160 mm

Outside Diameter:

239.5 mm

Thickness:

76 mm

Weight:

11.4 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

232000 N

Static load Capacity, Radial (Cor):

325000 N

Specifications:

Structure:

Double row angular contact ball bearings

Number of Rows:

Two

Load Direction:

Radial and axial loads

Bearing Material:

Bearing steel

Cage Type:

Machined Brass Cage

Seals Type:

Open

Rolling Mlement Material:

Bearing steel

Bore Type:

Cylindrical

System of Measurement:

metric

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

537406 bearings ( 160 mm x 239.5 mm x 76 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.

Part Number	537406
Interchangeable	FAG 537406
Desgin Figure	2
Cage	Machined Brass Cage
Arrangement	DB (<>) Back-to-Back
Seal	Open
Bearing Type	Angular Contact Ball Bearings, double row non-separable Thrust bearings for wire mills
Bearing Weight [lb]	25.132
d φ Inside [inch]	6.299
D Φ Outside [inch]	9.429
B Width [inch]	2.992
B_i Width [inch]	2.992
r_s min Chamfer	2.1 mm
r_1s min Chamfer	2 mm
C_r Radial Dynamic [lbf]	52153
C_0r Radial Static [lbf]	73060
D₁ min [inch]	6.693
D₂ max [inch]	9.094
r_g max Fillet radius [inch]	0.083
r_g1 max Fillet radius [inch]	0.079
