510043 Bore 530 Mm, Tapered Roller Bearings, O-arrangement
The 510043 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.
The 510043 bearing is a Tapered Roller Bearings, double row, in metric dimensions O-arrangement with an inner diameter of 530 mm , an outer diameter of 710 mm, a width of 190 mm. Bearing steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, Its dynamic radial rated load is approximately 3050000 N, its static radial rated load is approximately 7800000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
510043 bearings ( 530 mm x 710 mm x 190 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.
| Part Number | 510043 |
| Interchangeable | FAG 510043 |
| Desgin Figure | 2 |
| Cage | Stamping steel cage |
| Arrangement | back-to-back (<>) |
| Seal | Open |
| Bearing Type | Tapered Roller Bearings, double row, in metric dimensions O-arrangement |
| Other | spacer with radial lubrication grooves |
| Bearing Weight [lb] | 427.692 |
| d φ Inside [inch] | 20.866 |
| D Φ Outside [inch] | 27.953 |
| T Cone [inch] | 7.480 |
| C Cup [inch] | 5.354 |
| rs min Chamfer Cup | 2.5 mm |
| r1s min Chamfer Cone | 6 mm |
| Cr Radial Dynamic [lbf] | 685640 |
| C0r Radial Static [lbf] | 1753440 |
| Factor | |
| e | 0.41 |
