504083 Bore 150 Mm, Angular Contact Ball Bearings, Double Row For Wire Mills, Machined Brass Cage
The 504083 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.
The 504083 bearing is a Angular Contact Ball Bearings, double row non-separable Thrust bearings for wire mills with an inner diameter of 150 mm , an outer diameter of 240 mm, a width of 84 mm. Bearing steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, Its dynamic radial rated load is approximately 240000 N, its static radial rated load is approximately 335000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
504083 bearings ( 150 mm x 240 mm x 84 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.
| Part Number | 504083 |
| Interchangeable | FAG 504083 |
| Desgin Figure | 1 |
| Cage | Machined Brass Cage |
| Arrangement | DF (><) Front-to-Front |
| Seal | Open |
| Bearing Type | Angular Contact Ball Bearings, double row non-separable Thrust bearings for wire mills |
| Bearing Weight [lb] | 34.833 |
| d φ Inside [inch] | 5.905 |
| D Φ Outside [inch] | 9.449 |
| B Width [inch] | 3.307 |
| Bi Width [inch] | 3.307 |
| rs min Chamfer | 1.5 mm |
| r1s min Chamfer | 1 mm |
| Cr Radial Dynamic [lbf] | 53952 |
| C0r Radial Static [lbf] | 75308 |
| D1 min [inch] | 6.102 |
| D2 max [inch] | 9.173 |
| rg max Fillet radius [inch] | 0.059 |
| rg1 max Fillet radius [inch] | 0.039 |
