3975-3926 Single Row High Speed Tapered Roller Bearings

🔍

3975-3926

Bore Diameter:50.8 mm

Outside Diameter:12.713 mm

Width:30.048 mm

Min. Order:2 Piece

The 3975-3926 bearing is a Tapered Roller Bearings with an inner diameter of 50.8 mm , an outer diameter of 12.713 mm, a width of 30.048 mm. It typically uses p0/p6/p5/p4/p2 grade precision tolerances and features a Steel cage, Steel balls, steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 139000, its static radial rated load is approximately 191000. It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Reducer, Papermaking Machinery, Railway Vehicle

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

50.8 mm

Outside Diameter:

12.713 mm

Thickness:

30.048 mm

Cone Width (B):

30.048

Cup Width (C):

26.988

Performance Data:

Dynamic load Capacity, Radial (Cr):

139000

Static load Capacity, Radial (Cor):

191000

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Number of Rows:

Single

Demensions:

50.8 *12.713*30.048

Brand:

Z&K/Neutral / OEM

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Precision Rating:

p0/p6/p5/p4/p2

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Bearing Material:

Bearing Steel

Cage material:

Steel

Ball Material:

Steel

Roller Material:

steel

Series:

3900

Cone Number:

3975

Cup Number:

3926

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

10 Piece

Production Capacity:

1000PCS/Year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

3975-3926 Single Row High Speed Tapered Roller Bearings
3975-3926 Single Row High Speed Tapered Roller Bearings
Bearing NO.:	3975-3926	MOQ:	1PCS
Series:	3900	Material	Bearing steel
Cone Part NO.:	3975	Aa (mm):	1.5
Cup Part NO.:	3926	Ab (mm):	2
Bore (mm)d:	50.8	Db (mm):	98.04
Cup Outer Diameter(mm)D:	112.713	db(mm):	68
Cone Width(mm)B:	30.048	R(mm):	3.6
Cup Width(mm)C:	26.988	r (mm):	3.3
Bearing Width (mm)T:	33.34	Da(mm):	106.17
Dynamic load rating (C₉₀)N:	36000	K:	1.45
Dynamic load rating (C₁)N:	139000	e:	0.4
Static Radial Rating (CO)N:	191000	Y:	1.49
Dynamic Thrust Ratin(Ca₉₀)N:	24800	Cg:	0.109
Applicable Industries:	Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company	Contact Bonnie:	Email:[email protected]
Applicable Industries:		Contact Bonnie:	Email:[email protected]
