390A - 394A TS Single Row Tapered Roller Bearings

🔍

390A - 394A

Bore Diameter:63.5 mm

Outside Diameter:110 mm

Width:21.999 mm

Min. Order:2 Piece

The 390A - 394A bearing is a Tapered Roller Bearings with an inner diameter of 63.5 mm , an outer diameter of 110 mm, a width of 21.999 mm. It typically uses p0/p6/p5/p4/p2 grade precision tolerances and features a Steel cage, Steel balls, steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 98900, its static radial rated load is approximately 125000. It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Reducer, Papermaking Machinery, Railway Vehicle

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

63.5 mm

Outside Diameter:

110 mm

Thickness:

21.999 mm

Chamfer (R):

1.5 mm

Cone Width (B):

21.996 mm

Cup Width (C):

18.824 mm

Chamfer (r):

1.27mm

Performance Data:

Dynamic load Capacity, Radial (Cr):

98900

Static load Capacity, Radial (Cor):

125000

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Number of Rows:

Single

Demensions:

63.5*110*21.999

Brand:

Z&K/Neutral / OEM

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Precision Rating:

p0/p6/p5/p4/p2

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Bearing Material:

Bearing Steel

Cage material:

Steel

Ball Material:

Steel

Roller Material:

steel

Series:

395

Cone Number:

390A

Cup Number:

394A

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

10 Piece

Production Capacity:

1000PCS/Year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

390A - 394A TS Single Row Tapered Roller Bearings
390A - 394A TS Single Row Tapered Roller Bearings
Bearing NO.:	390A - 394A	MOQ:	1PCS
Series:	365	Material	Bearing steel
Cone Part NO.:	390A	Db (mm):	101.09
Cup Part NO.:	394A	Da(mm):	105.4
Bore (mm):	63.5	da (mm):	70
Cup Outer Diameter(mm):	110	r (mm):	1.27
Cone Width(mm):	21.996	R(mm):	1.5
Cup Width(mm):	18.824	K:	1.45
Bearing Width (mm):	21.999	e :	0.4
Dynamic load rating (C₉₀)N:	25600	Y :	1.49
Dynamic load rating (C₁)N:	98900	G1 :	56
Static Radial Rating (CO)N:	125000	G2:	21.4
Dynamic Thrust Ratin(Ca₉₀)N:	17600	Cg:	0.0984
Applicable Industries:	Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company	Contact Bonnie:	Email:[email protected]
Applicable Industries:		Contact Bonnie:	Email:[email protected]
