3812 Angular Contact Ball Bearings Open, Solid Polyamide Snap Cage

🔍

3812

Bore Diameter:60 mm

Outside Diameter:78 mm

Width:14 mm

Weight:0.146 kg

Min. Order:1 Piece

The 3812

The 3812 bearing is a Angular contact ball bearings Double row Open with an inner diameter of 60 mm , an outer diameter of 78 mm, a width of 14 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 14184 N, its static radial rated load is approximately 17078 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

60 mm

Outside Diameter:

78 mm

Thickness:

14 mm

Weight:

0.146 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

14184 N

Static load Capacity, Radial (Cor):

17078 N

Fatigue Load Limit, Radial:

956 N

Reference speed (Grease rpm):

4692

Limiting speed (Oil rpm):

8777

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

double

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVH = Solid polyamide snap cage, ball-guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

38..-B-TVH

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	3812
Design Type	B = Bearing without filling slot
Bearing Type	Angular contact ball bearings Double row Open
Series	38..-B-TVH
Contact angle - α [°]	25
Rows NO.	double
Manufacturer Part Code	3812
Radial internal clearances	CN
Cage	TVH = Solid polyamide snap cage, ball-guided
Lubricant	Without
Seal type	Open
Heat stabilization	SN = up to 120°
m Weight [kg]	0.146
Reference From	FAG 3812
Dimensions
d φ Inside [inch]	2.362
D Φ Outside [inch]	3.071
B Width [inch]	0.551
r(min.) [inch]	0.012
D₁ [inch]	2.869
D₂ [inch]	2.942
d₁ [inch]	2.642
d₂ [inch]	2.586
a [inch]	1.500
Performance
C_r Radial Dynamic [N]	14184
C_0r Radial static [N]	17078
C_ur Radial Fatigue [N]	956
n_G Limiting speed (oil) [r/min]	8777
n_B Reference speed (grease) [r/min]	4692
Mounting dimensions
d_a(min.) [inch]	2.441
D_a(max.) [inch]	2.992
r_a(max.) [inch]	0.012
