3810 Angular Contact Ball Bearings Open, Solid Polyamide Snap Cage

🔍

3810

Bore Diameter:50 mm

Outside Diameter:65 mm

Width:12 mm

Weight:0.091 kg

Min. Order:1 Piece

The 3810

The 3810 bearing is a Angular contact ball bearings Double row Open with an inner diameter of 50 mm , an outer diameter of 65 mm, a width of 12 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 8453 N, its static radial rated load is approximately 10189 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

50 mm

Outside Diameter:

65 mm

Thickness:

12 mm

Weight:

0.091 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

8453 N

Static load Capacity, Radial (Cor):

10189 N

Fatigue Load Limit, Radial:

579 N

Reference speed (Grease rpm):

5395

Limiting speed (Oil rpm):

8078

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

double

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVH = Solid polyamide snap cage, ball-guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

38..-B-TVH

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	3810
Design Type	B = Bearing without filling slot
Bearing Type	Angular contact ball bearings Double row Open
Series	38..-B-TVH
Contact angle - α [°]	25
Rows NO.	double
Manufacturer Part Code	3810
Radial internal clearances	CN
Cage	TVH = Solid polyamide snap cage, ball-guided
Lubricant	Without
Seal type	Open
Heat stabilization	SN = up to 120°
m Weight [kg]	0.091
Reference From	FAG 3810
Dimensions
d φ Inside [inch]	1.969
D Φ Outside [inch]	2.559
B Width [inch]	0.472
r(min.) [inch]	0.012
D₁ [inch]	2.385
D₂ [inch]	2.417
d₁ [inch]	2.217
d₂ [inch]	2.174
a [inch]	1.220
Performance
C_r Radial Dynamic [N]	8453
C_0r Radial static [N]	10189
C_ur Radial Fatigue [N]	579
n_G Limiting speed (oil) [r/min]	8078
n_B Reference speed (grease) [r/min]	5395
Mounting dimensions
d_a(min.) [inch]	2.047
D_a(max.) [inch]	2.480
r_a(max.) [inch]	0.012
