3204-BD-TVH Angular Contact Ball Bearings Open, Solid Polyamide Snap Cage

🔍

3204-BD-TVH

Bore Diameter:20 mm

Outside Diameter:47 mm

Width:20.6 mm

Weight:0.146 kg

Min. Order:1 Piece

The 3204-BD-TVH They are widely used in equipment with high requirements for axial rigidity and space efficiency, including: automotive wheel hubs, industrial robots (wrist), machine tool spindles (lathes), electric fans (spindle supports), turbochargers, and medical devices (high-speed centrifuges).

The 3204-BD-TVH bearing is a Angular contact ball bearings Double row Open with an inner diameter of 20 mm , an outer diameter of 47 mm, a width of 20.6 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 20599 N, its static radial rated load is approximately 12898 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

20 mm

Outside Diameter:

47 mm

Thickness:

20.6 mm

Weight:

0.146 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

20599 N

Static load Capacity, Radial (Cor):

12898 N

Fatigue Load Limit, Radial:

886 N

Reference speed (Grease rpm):

14694

Limiting speed (Oil rpm):

16089

Specifications:

Structure:

Double row angular contact ball bearings

Number of Rows:

double

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVH = Solid polyamide snap cage, ball-guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

32..-BD-XL-TVH

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

3204-BD-TVH bearings ( 20 mm x 47 mm x 20.6 mm) have the advantages of It can withstand radial and bidirectional axial loads simultaneously, has a compact structure, good rigidity, and is easy to install, and are therefore widely used in the Automotive wheel hub units, pumps, compressors, industrial gearboxes, and machine tool spindles.

Part Number	3204-BD-TVH
Design Type	B = Bearing without filling slot
Bearing Type	Angular contact ball bearings Double row Open
Series	32..-BD-XL-TVH
X-Life	XL long life design
Contact angle - α [°]	30
Rows NO.	double
Manufacturer Part Code	3204-BD-TVH
Radial internal clearances	CN
Cage	TVH = Solid polyamide snap cage, ball-guided
Equivalent	3204-BD-TVH
Lubricant	Without
Seal type	Open
Heat stabilization	SN = up to 120°
m Weight [kg]	0.146
Reference From	FAG 3204-BD-TVH
Dimensions
d φ Inside [inch]	0.787
D Φ Outside [inch]	1.850
B Width [inch]	0.811
r(min.) [inch]	0.039
D₁ [inch]	1.579
D₂ [inch]	1.663
d₁ [inch]	1.213
d₂ [inch]	1.150
a [inch]	1.098
Performance
C_r Radial Dynamic [N]	20599
C_0r Radial static [N]	12898
C_ur Radial Fatigue [N]	886
n_G Limiting speed (oil) [r/min]	16089
n_B Reference speed (grease) [r/min]	14694
Mounting dimensions
d_a(min.) [inch]	1.008
D_a(max.) [inch]	1.630
r_a(max.) [inch]	0.039

The 3204-BD-TVH Double-row angular contact ball bearings primarily consist of an integral inner ring (or double-half inner ring), an integral outer ring, two rows of balls, and a cage. The contact angle is typically 25°, 30°, or 35°, with the two rows of balls arranged back-to-back, providing bidirectional axial load capacity.

A single bearing can withstand both radial and bidirectional axial loads, eliminating the need for paired installation. They offer high axial rigidity and excellent resistance to overturning moments, making them suitable for handling instantaneous overloads. The integral design simplifies installation, saves space, and is widely used in applications requiring compact designs.
