3203-BD-XL-Z-TVH Solid Polyamide Snap Cage Angular Contact Ball Bearings, Sealed

🔍

3203-BD-XL-Z-TVH

Bore Diameter:17 mm

Outside Diameter:40 mm

Width:17.5 mm

Weight:0.093 kg

Min. Order:1 Piece

The 3203-BD-XL-Z-TVH They are widely used in equipment with high requirements for axial rigidity and space efficiency, including: automotive wheel hubs, industrial robots (wrist), machine tool spindles (lathes), electric fans (spindle supports), turbochargers, and medical devices (high-speed centrifuges).

The 3203-BD-XL-Z-TVH bearing is a Angular contact ball bearings Double row sealed with an inner diameter of 17 mm , an outer diameter of 40 mm, a width of 17.5 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 15481 N, its static radial rated load is approximately 9495 N. It uses CN standard radial clearance, Z = Non-contact shield on one Side type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 3203-BD-Z-TVH

Dimensions:

Inside Diameter:

17 mm

Outside Diameter:

40 mm

Thickness:

17.5 mm

Weight:

0.093 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

15481 N

Static load Capacity, Radial (Cor):

9495 N

Fatigue Load Limit, Radial:

651 N

Reference speed (Grease rpm):

16594

Limiting speed (Oil rpm):

14593

Specifications:

Old Designations:

3203-BD-Z-TVH

Structure:

Double row angular contact ball bearings

Number of Rows:

double

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVH = Solid polyamide snap cage, ball-guided

Seals Type:

Z = Non-contact shield on one Side

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-20 to 120 °C

Series:

32..-BD-XL-Z-TVH

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

3203-BD-XL-Z-TVH bearings ( 17 mm x 40 mm x 17.5 mm) have the advantages of It can withstand radial and bidirectional axial loads simultaneously, has a compact structure, good rigidity, and is easy to install, and are therefore widely used in the Automotive wheel hub units, pumps, compressors, industrial gearboxes, and machine tool spindles.

Part Number	3203-BD-XL-Z-TVH
Design Type	B = Bearing without filling slot
Bearing Type	Angular contact ball bearings Double row sealed
Series	32..-BD-XL-Z-TVH
X-Life	XL long life design
Contact angle - α [°]	30
Rows NO.	double
Manufacturer Part Code	3203-BD-Z-TVH
Radial internal clearances	CN
Cage	TVH = Solid polyamide snap cage, ball-guided
Equivalent	3203-BD-Z-TVH
Lubricant	GA14 = Ball bearing grease, low noise
Seal type	Z = Non-contact shield on one Side
Heat stabilization	SN = up to 120°
m Weight [kg]	0.093
Reference From	FAG 3203-BD-XL-Z-TVH
Dimensions
d φ Inside [inch]	0.669
D Φ Outside [inch]	1.575
B Width [inch]	0.689
r(min.) [inch]	0.024
D₁ [inch]	1.336
D₂ [inch]	1.421
d₁ [inch]	1.016
d₂ [inch]	0.962
a [inch]	0.925
Performance
C_r Radial Dynamic [N]	15481
C_0r Radial static [N]	9495
C_ur Radial Fatigue [N]	651
n_G Limiting speed (oil) [r/min]	14593
n_B Reference speed (grease) [r/min]	16594
Mounting dimensions
d_a(min.) [inch]	0.835
D_a(max.) [inch]	1.409
r_a(max.) [inch]	0.024

The 3203-BD-XL-Z-TVH Double-row angular contact ball bearings primarily consist of an integral inner ring (or double-half inner ring), an integral outer ring, two rows of balls, and a cage. The contact angle is typically 25°, 30°, or 35°, with the two rows of balls arranged back-to-back, providing bidirectional axial load capacity.

A single bearing can withstand both radial and bidirectional axial loads, eliminating the need for paired installation. They offer high axial rigidity and excellent resistance to overturning moments, making them suitable for handling instantaneous overloads. The integral design simplifies installation, saves space, and is widely used in applications requiring compact designs.
