249750CAW33 Spherical Roller Bearings, Brass Cage

🔍

249750CAW33

Bore Diameter:750 mm

Outside Diameter:1000 mm

Width:250 mm

Weight:560 kg

Min. Order:1 Piece

The 249750CAW33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 249750CAW33 bearing is a Spherical roller bearings, double row with an inner diameter of 750 mm , an outer diameter of 1000 mm, a width of 250 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 7698859 N, its static radial rated load is approximately 17999823 N. It uses Normal standard radial clearance, open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

750 mm

Outside Diameter:

1000 mm

Thickness:

250 mm

Weight:

560 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

7698859 N

Static load Capacity, Radial (Cor):

17999823 N

Reference speed (Grease rpm):

278

Limiting speed (Oil rpm):

469

Specifications:

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Normal

Bearing Material:

High-carbon chromium steel

Cage Type:

CA = brass cage

Seals Type:

open

Rolling Mlement Material:

High-carbon chromium steel

Bore Type:

Z = cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

249..-CA/W33

Rolling Element:

spherical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

249750CAW33 bearings ( 750 mm x 1000 mm x 250 mm) have the advantages of Self-aligning, high load-bearing capacity, and impact resistant, and are therefore widely used in the Mining machinery, metallurgical equipment, papermaking machinery, vibrating screens, wind turbines, and large industrial gearboxes.

Part Number	249750CAW33
Manufacturer Part Code	249/750CA/W33
Internal design	CA = Retaining flanges on the inner ring, guide ring centred on the inner ring, machined brass cage
Bearing Type	Spherical roller bearings, double row
m Weight [lb]	1234.576
Seal type	open
Series	249..-CA/W33
Cage	CA = brass cage
Lubrication	W33 = Annular groove and three lubrication holes in the outer ring
Bore Type	Z = cylindrical bore
Radial internal clearance	Normal
Units	Metric
C_r Dynamic Radial [lbf]	1730703
C_0r Static Radial [lbf]	4046360
P_u Fatigue Radial [lbf]	247099
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	+200
n_B Speed ratings (grease) [rpm]	278
n_G Speed ratings (oil) [rpm]	469
Heat stabilization	392 °F (200 °C)
Dimension
d φ Inside [inch]	29.528
D Φ Outside [inch]	39.370
B Width [inch]	9.843
b [inch]	0.878
K [inch]	0.472
d₂ [inch]	32.677
D₁ [inch]	36.063
r_a(max.) Fillet [inch]	0.197
r₁,r₂(min.) Fillet [inch]	0.236
Abutment dimensions
d_a(min.) [inch]	30.433
D_a(max.) [inch]	38.464
Calculation factor
e	0.22
Y₁	3
Y₂	4.6
Y₀	2.8

The 249750CAW33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
