249/1180CAK30F/W33 11801540355mm Spherical Roller Bearing

🔍

249/1180CAK30F/W33

Bore Diameter:1180 mm

Outside Diameter:1540 mm

Width:355 mm

Weight:1800 kg

Reference FOB Price:US80000 ~ 92000 / Piece

Min. Order:1 Piece

The 249/1180CAK30F/W33 bearing is a Spherical roller bearing with an inner diameter of 1180 mm , an outer diameter of 1540 mm, a width of 355 mm. It typically uses P0 grade precision tolerances and features a brass cage, gcr15 rings. It primarily bears radial/Axial, Its dynamic radial rated load is approximately 15751, its static radial rated load is approximately 40500. It uses C0/C3 standard radial clearance, no seals type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Spherical

Application: Cement equipment

Dimensions:

Inside Diameter:

1180 mm

Outside Diameter:

1540 mm

Thickness:

355 mm

Weight:

1800 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

15751

Static load Capacity, Radial (Cor):

40500

Reference speed (Grease rpm):

130

Limiting speed (Oil rpm):

240

Specifications:

Old Designations:

249/1180CAF/W33

HS Code:

84823000.00

Structure:

spherical roller

Number of Rows:

double row

Demensions:

1180*1540*355mm

Brand:

MONTON

Radial Clearance Trade No.:

C0/C3

Precision Rating:

Vibration:

Z2V2

Load Direction:

radial/Axial

Bearing Material:

Gcr15

Cage Type:

Brass

Cage material:

brass

Seals Type:

no seals

Number of Roller:

120

Roller Material:

gcr15

Transaction Information:

Transport Package:

Wooden case

Service:

OEM

Shipping Ways:

Sea

Country of Origin:

China

Quality Control:

Self-control

Stock:

10 Piece

Production Capacity:

100PCS/WEEK

Port:

Shanghai

Payment term:

T/T

Delivery time:

45 days

Detailed description

Designations

Principal dimensions

Basic load ratings

Fatigue
load
limit

Speed ratings

Dimensions

Abutment and illet dimensions

Calculation factors

Mass

Bearing with cylindrical bore

Bearing with tapered bore

dynamic C

static C0

Reference
speed

Limiting
speed

d2
≈

D1
≈

r1,2
min

da min

da max

Da max

ra max

–

r/min

–

249/1180CAF/W33

249/1180CAK30F/W33

1180

1540

355

15751

40500

2160

130

240

1297

1422

22.3

7.5

1208

–

1512

0.2

3.4

3.2

1800

CA, CAC Retaining flanges on the inner ring, guide ring centred on the inner ring, machined brass cage (unless one of the cage design suffixes is specified)

K30 Tapered bore, taper 1:30

F Machined steel cage, inner ring centred

W33 Annular groove and three lubrication holes in the outer ring

C3 Radial internal clearance greater than Normal
