24120 CCK30/C4W33 Spherical Roller Bearings, Stamped Steel Cages, Tapered Bore, Taper 1:30
The 24120 CCK30/C4W33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.
The 24120 CCK30/C4W33 bearing is a Spherical roller bearings, double row with an inner diameter of 100 mm , an outer diameter of 165 mm, a width of 65 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 462922 N, its static radial rated load is approximately 634784 N. It uses C4 standard radial clearance, open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
24120 CCK30/C4W33 bearings ( 100 mm x 165 mm x 65 mm) have the advantages of Self-aligning, high load-bearing capacity, and impact resistant, and are therefore widely used in the Mining machinery, metallurgical equipment, papermaking machinery, vibrating screens, wind turbines, and large industrial gearboxes.
| Part Number | 24120 CCK30/C4W33 |
| Manufacturer Part Code | 24120CCK30/C4W33 |
| Internal design | CC = Flangeless inner ring, guide ring centred on the inner ring, two stamped steel cages |
| Bearing Type | Spherical roller bearings, double row |
| m Weight [lb] | 12.456 |
| Seal type | open |
| Series | 241..-CCK30/W33 |
| Cage | CC = stamped steel cages |
| Lubrication | W33 = Annular groove and three lubrication holes in the outer ring |
| Bore Type | K30 = Tapered bore, taper 1:30 |
| Radial internal clearance | C4 |
| Units | Metric |
| Cr Dynamic Radial [lbf] | 104064 |
| C0r Static Radial [lbf] | 142699 |
| Pu Fatigue Radial [lbf] | 14140 |
| Operating temperature - T(min) [°C] | -30 |
| Operating temperature - T(max) [°C] | +200 |
| nB Speed ratings (grease) [rpm] | 2356 |
| nG Speed ratings (oil) [rpm] | 3172 |
| Heat stabilization | 392 °F (200 °C) |
| Dimension | |
| d φ Inside [inch] | 3.937 |
| D Φ Outside [inch] | 6.496 |
| B Width [inch] | 2.559 |
| b [inch] | 0.173 |
| K [inch] | 0.079 |
| d2 [inch] | 4.449 |
| D1 [inch] | 5.551 |
| ra(max.) Fillet [inch] | 0.079 |
| r1,r2(min.) Fillet [inch] | 0.079 |
| Angular misalignment | 2.5 degrees |
| Abutment dimensions | |
| da(min.) [inch] | 4.370 |
| Da(max.) [inch] | 6.063 |
| Calculation factor | |
| e | 0.37 |
| Y1 | 1.8 |
| Y2 | 2.7 |
| Y0 | 1.8 |
The 24120 CCK30/C4W33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.
Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
