241/670-2CS5K30/C3HGEA8 Spherical Roller Bearings, Machined Metal, Tapered Bore, Taper 1:30
The 241/670-2CS5K30/C3HGEA8 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.
The 241/670-2CS5K30/C3HGEA8 bearing is a Sealed spherical roller bearings with an inner diameter of 670 mm , an outer diameter of 1090 mm, a width of 412 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 16401896 N, its static radial rated load is approximately 28979955 N. It uses C3H standard radial clearance, 2CS5 = Contact seal, HNBR, on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
241/670-2CS5K30/C3HGEA8 bearings ( 670 mm x 1090 mm x 412 mm) have the advantages of High load-bearing capacity, impact resistant, self-aligning, and easy to install, and are therefore widely used in the Wind turbine main shaft, large ship main shaft, giant construction machinery.
| Part Number | 241/670-2CS5K30/C3HGEA8 |
| Manufacturer Part Code | 241/670-2CS5K30/C3HGEA8 |
| Bearing Type | Sealed spherical roller bearings |
| m Weight [lb] | 3267.217 |
| Seal type | 2CS5 = Contact seal, HNBR, on both sides |
| Series | 241..-2CS5K30/C3HGEA8 |
| Cage | Machined metal |
| Lubrication | GEA8 = Filled to 60 – 80% with LGEV 2 grease |
| Bore Type | K30 = Tapered bore, taper 1:30 |
| Radial internal clearance | C3H |
| Units | Metric |
| Sealing type | Contact |
| Cr Dynamic Radial [lbf] | 3687146 |
| C0r Static Radial [lbf] | 6514693 |
| Pu Fatigue Radial [lbf] | 391012 |
| Operating temperature - T(min) [°C] | -30 |
| Operating temperature - T(max) [°C] | +200 |
| nG Speed ratings (oil) [rpm] | 35 |
| Heat stabilization | 392 °F (200 °C) |
| Dimension | |
| d φ Inside [inch] | 26.378 |
| D Φ Outside [inch] | 42.913 |
| B Width [inch] | 16.220 |
| b [inch] | 0.878 |
| K [inch] | 0.472 |
| d2 [inch] | 29.646 |
| D1 [inch] | 38.346 |
| ra(max.) Fillet [inch] | 0.236 |
| r1,r2(min.) Fillet [inch] | 0.295 |
| Angular misalignment | 2.5 degrees |
| Da(max.) [inch] | 41.653 |
| Calculation factor | |
| e | 0.35 |
| Y1 | 1.9 |
| Y2 | 2.9 |
| Y0 | 1.8 |
The 241/670-2CS5K30/C3HGEA8 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.
Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
