240tp178 Thrust Cylindrical Roller Bearing, Window-type Steel Cage

🔍

240tp178

Bore Diameter:609.6 mm

Outside Diameter:863.6 mm

Width:139.7 mm

Weight:269 kg

Min. Order:1 Piece

The 240tp178 Cylindrical roller thrust bearings are specifically designed for applications requiring heavy axial loads and stringent positioning accuracy. Classic applications include heavy-duty vertical lathe tables, marine propeller shaft thrust devices, large gearboxes, wind turbine main gearboxes, rolling mill pressing mechanisms, and crane slewing bearings.

The 240tp178 bearing is a Thrust cylindrical roller bearing with an inner diameter of 609.6 mm , an outer diameter of 863.6 mm, a width of 139.7 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic axial rated load is approximately 5695584 N, its static axial rated load is approximately 33495550 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

609.6 mm

Outside Diameter:

863.6 mm

Thickness:

139.7 mm

Weight:

269 KG

Dynamic load Capacity, axial:

5695584 N

Static load Capacity, axial:

33495550 N

Limiting speed (Oil rpm):

320

Specifications:

Structure:

Cylindrical Roller Thrust Bearings

Number of Rows:

Two or Three

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Cage Type:

window-type steel cage

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Metric

Series:

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

240tp178 bearings ( 609.6 mm x 863.6 mm x 139.7 mm) have the advantages of extremely high axial load capacity, high rigidity, compact axial structure, and a detachable design for easy installation, and are therefore widely used in the Machine tool worktables, extruders, differentials, wind power equipment, and oil drilling machinery.

Part Number	240tp178
Design type	TP: Two or three cylindrical rollers per cage pocket
Bearing Type	Thrust cylindrical roller bearing
Interchangeable	TIMKEN 240tp178
Manufacturer Part Code	240 TP 178
Series	TP
Cage	window-type steel cage
Units	Metric
Tolerance class	PN (ABEC-1)
C_0a Axial Static [lbf]	7529799
C_a Axial Dynamic [lbf]	1280367
n_G Speed ratings (oil) [rpm]	320
d φ Inside [inch]	24.0000
D Φ Outside [inch]	33.9999
T Width [inch]	5.5000
T₁ Cage Position [inch]	1.5000
r Fillet Radius [inch]	0.3740
d₁ [inch]	24.1259
D₁ [inch]	33.8739
E (Max) Shoulder Diameter Housing [inch]	25.0000
H (Min) Shoulder Diameter Shaft [inch]	32.9999
Weight [lb]	593.0374

The 240tp178 Cylindrical roller thrust bearings mainly consist of a shaft ring, a housing ring, cylindrical rollers, and a cage assembly. The rollers are arranged radially, forming a line contact load-bearing structure.

The advantages of cylindrical roller thrust bearings include extremely high axial load capacity, excellent rigidity, and a low coefficient of friction. Optimized roller end faces and flanges can accommodate slight eccentricity and impact loads, while also featuring a compact structure and high rotational accuracy.
