24092-B-MB-C4 Spherical Roller Bearings With Central Rib Cylindrical Bore

🔍

24092-B-MB-C4

Bore Diameter:460 mm

Outside Diameter:680 mm

Width:218 mm

Weight:282 kg

Min. Order:1 Piece

The 24092-B-MB-C4 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 24092-B-MB-C4 bearing is a Spherical roller bearings With central rib Cylindrical bore with an inner diameter of 460 mm , an outer diameter of 680 mm, a width of 218 mm. GCr15, GCr15SiMn, SUJ2 rings, GCr15, SUJ2 rolling mlement. Its dynamic radial rated load is approximately 4749934 N, its static radial rated load is approximately 10599913 N. It uses C4 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

460 mm

Outside Diameter:

680 mm

Thickness:

218 mm

Weight:

282 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

4749934 N

Static load Capacity, Radial (Cor):

10599913 N

Fatigue Load Limit, Radial:

709929 N

Reference speed (Grease rpm):

405

Limiting speed (Oil rpm):

629

Specifications:

Old Designations:

24092BMBC4

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Bearing Material:

GCr15, GCr15SiMn, SUJ2

Cage Type:

MB = Solid brass cage, guided on inner ring

Rolling Mlement Material:

GCr15, SUJ2

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

240..-B-MB-C4

Rolling Element:

symmetrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

10 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

24092-B-MB-C4 bearings ( 460 mm x 680 mm x 218 mm) have the advantages of High load-bearing capacity, impact resistant, self-aligning, and easy to install, and are therefore widely used in the Wind turbine main shaft, large ship main shaft, giant construction machinery.

Part Number	24092-B-MB-C4
Design drawing	2
Design Type	B = with fixed central rib
Bore Type	Z = Cylindrical bore
RIC	C4
Row	2
Bearing Type	Spherical roller bearings With central rib Cylindrical bore
Manufacturer Part Code	24092BMBC4
Cage	MB = Solid brass cage, guided on inner ring
Measurement	Metric
d φ Inside [inch]	18.110
D Φ Outside [inch]	26.772
B Width [inch]	8.583
n_B Reference speed (grease) [min^–1]	405
n_G Limiting speed (oil) [min^–1]	629
Weight [kg]	282
r(min.) Chamfer [inch]	0.236
D₁ [inch]	23.752
d_s [inch]	0.492
n_s [inch]	0.925
C_r Radial Dynamic [lbf]	1067785
C_0r Radial static [lbf]	2382860
C_ur Radial Fatigue [lbf]	159592
Temperature - T(min)[°C]	-30
Temperature - T(max)[°C]	+200
Mounting dimensions
d_a(min.) [inch]	19.016
D_a(max.) [inch]	25.866
r_a(max.) [mm]	282
Calculation coefficient
e	0.31
Y₀	2.12
Y₁	2.16
Y₂	3.22

The 24092-B-MB-C4 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
