23992CA C3 W33 Spherical Roller Bearings, Brass Cage

🔍

23992CA C3 W33

Bore Diameter:460 mm

Outside Diameter:620 mm

Width:118 mm

Weight:105 kg

Min. Order:1 Piece

The 23992CA C3 W33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 23992CA C3 W33 bearing is a Spherical roller bearings, double row with an inner diameter of 460 mm , an outer diameter of 620 mm, a width of 118 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 2557836 N, its static radial rated load is approximately 4999868 N. It uses C3 standard radial clearance, open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

460 mm

Outside Diameter:

620 mm

Thickness:

118 mm

Weight:

105 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

2557836 N

Static load Capacity, Radial (Cor):

4999868 N

Reference speed (Grease rpm):

593

Limiting speed (Oil rpm):

973

Specifications:

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Bearing Material:

High-carbon chromium steel

Cage Type:

CA = brass cage

Seals Type:

open

Rolling Mlement Material:

High-carbon chromium steel

Bore Type:

Z = cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

239..-CA/W33

Rolling Element:

spherical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

23992CA C3 W33 bearings ( 460 mm x 620 mm x 118 mm) have the advantages of Self-aligning, extremely high load-bearing capacity, thinnest cross-section, low friction, suitable for confined spaces, and are therefore widely used in the Large crushers, mills, and rotary kilns.

Part Number	23992CA C3 W33
Manufacturer Part Code	23992CA/W33
Internal design	CA = Retaining flanges on the inner ring, guide ring centred on the inner ring, machined brass cage
Bearing Type	Spherical roller bearings, double row
m Weight [lb]	231.483
Seal type	open
Series	239..-CA/W33
Cage	CA = brass cage
Lubrication	W33 = Annular groove and three lubrication holes in the outer ring
Bore Type	Z = cylindrical bore
Radial internal clearance	C3
Units	Metric
C_r Dynamic Radial [lbf]	575001
C_0r Static Radial [lbf]	1123970
P_u Fatigue Radial [lbf]	79723
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	+200
n_B Speed ratings (grease) [rpm]	593
n_G Speed ratings (oil) [rpm]	973
Heat stabilization	392 °F (200 °C)
Dimension
d φ Inside [inch]	18.110
D Φ Outside [inch]	24.409
B Width [inch]	4.646
b [inch]	0.657
K [inch]	0.354
d₂ [inch]	20.315
D₁ [inch]	22.598
r_a(max.) Fillet [inch]	0.118
r₁,r₂(min.) Fillet [inch]	0.157
Angular misalignment	1.5 degrees
Abutment dimensions
d_a(min.) [inch]	18.701
D_a(max.) [inch]	23.819
Calculation factor
e	0.16
Y₁	4.2
Y₂	6.3
Y₀	4

The 23992CA C3 W33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
