23328CA Spherical Roller Bearing

🔍

23328CA

Bore Diameter:140 mm

Outside Diameter:300 mm

Width:118 mm

Weight:39.6 kg

The 23328CA bearing is a spherical roller bearing with an inner diameter of 140 mm , an outer diameter of 300 mm, a width of 118 mm. It typically uses P0 P6 P5 grade precision tolerances and open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

140 mm

Outside Diameter:

300 mm

Thickness:

118 mm

Weight:

39.6 KG

Specifications:

Structure:

roller bearing

Brand:

ZGCY

Precision Rating:

P0 P6 P5

Bearing Material:

GCr15/GCr15SiMn

Seals Type:

open

Transaction Information:

Payment term:

T/T, 30% T/T in advance .70% against copy of B/L.

Delivery time:

Detailed description

1 Company Introduction Jinan Yuanqing is specialized in the production of roller bearing . With superior quality, abundant stock and exellent service..especially in Spherical roller bearing (low noise,long life ,high precision,have dealer in EU market )

2 Main Products Spherical Roller Bearing

Cylindrical Roller Bearing

Tapered Roller Bearing

Spherical Thrust Roller Bearing

Deep groove ball bearing

OEM service

3 ID size 100MM-1200MM

4 Certificate ISO9001-2000

5 23328CA Description 23328CA Spherical roller bearings are inherently self-aligning and very robust.They have two rows of rollers which make the bearings able to carry heavy loads.The spherical roller bearings mainly includes CC, CA, CAE, MB and E type.

6 23328CA Material GCr15/GCr15SiMn

7 23328CA Cage Brass/Steel

8 23328CA Hardness HRC60-HRC64

9 23328CA Closures Unsealed/Sealed

10 23328CA Grade P0 P6 P5

11 23328CA Clearance C0,C3,C4

12 23328CA Lubrication Oil or grease

13 23328 Structure Spherical Roller Bearing CC series

Spherical Roller Bearing CA series

Spherical Roller Bearing CAE series

Spherical Roller Bearing MB series

Spherical Roller Bearing E series

18 23328CA Features These bearings are featuredy the extremely big axial load carrying capacity and meanwhile they can also carry certain radial load

19 23328CA Packing 1.For small ones:anti-rust oil+vacuum plastic bag+paper box+wooden box

2.For big ones:anti-rust oil+waterproof belt+professional belt+wooden box

3.Do it as your request .

20 Application 23328CA are mainly use in Steel industry, oil industry,cement industry,mining&construction, papermaking machinery,rolling mill, sugar mill, vibrating screens, conveyors, air blower, transmissions, and other heavy machinery.etc

21 Payment Terms T/T, 30% T/T in advance .70% against copy of B/L.

22 23328CA Brand ZGCY

23 23328CA Delivery time: 15 days

24 Mode 23328CA spherical roller bearing

23328CA Inside diameter 140

23328CA Outside diameter 300

23328CA Thickness 118

23328CA Weight 39.6

23328CA Dynamic load rating 1260

23328CA Static load rating 1790

25 C2 Radial clearance is less than the basic group

C0 Radial clearance of basic group,not marked

C3 Radial clearance is more than the basic group

C4 Radial clearance is more than C3

C5 Radial clearance is more than C4

K Tapered bore,taper 1:12

K30 Tapered bore ,taper 1:30

W33 Outer ring with lubrication goove and three lubrication holes

VA405 Special bearing for vibration machinery

E With one guide ring guided by the outer ring ,two window type steel cage

MB Inner ring with the whole medium rim .inner ring with rims at two sides ,machined brass cage with inner guide

MA Inner ring with the whole medium rim .inner ring with rims at two sides ,machined brass cage with outer guide

We,ZGCY BEARINGS,specilized in manufacturing & exporting of 23328CA bearing for many years.We have quantity of 23328CA bearing in stock,and we also have great variety of other bearing.With the advantages,our 23328CA bearing own more competitive price and high good quality than other exporter..We ,ZGCY BEARINGS is the leading manufacturer of 23328CA bearing and we promise promptly delivery,professional service.To satisfy the different need of our clients,we could also supply deep groove ball bearing,cylinder roller bearing, tapered roller bearing and other bearings.It is priority to us to supply best service to our clients.If you are interested in 23328CA bearing,plz feel free to call or email us.
