23252 CA／W33 Spherical Roller Bearing 260mm X 480mm X 174mm

🔍

23252 CA／W33

Bore Diameter:260 mm

Outside Diameter:480 mm

Width:174 mm

Weight:144kg kg

The 23252 CA／W33 bearing is a Spherical Roller Bearing with an inner diameter of 260 mm , an outer diameter of 480 mm, a width of 174 mm. It typically uses P0 - P2 grade precision tolerances and Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

260 mm

Outside Diameter:

480 mm

Thickness:

174 mm

Weight:

144kg KG

Specifications:

Structure:

Spherical Roller Bearing

Brand:

Bassing on you

Precision Rating:

P0 - P2

Bearing Material:

Grc15/Chrome Steel

Seals Type:

Open

Transaction Information:

Payment term:

TT / LC / Western Union

Delivery time:

5-7days after order confirmed

Detailed description

Spherical Roller Bearing 23252 CA／W33 260mm x 480mm x 174mm

About Product :

Model Number	23252 CA／W33
Part Name	Spherical Roller Bearing
Precision Rating	ABEC-1 to ABEC-9
Vibration and Noise	Z0V0 / Z1V1 / Z2V2 / Z3V3
Material	Gcr15 Chrome Steel
Number of Row	Double Row
Cage	Brass Cage
*Dimensions(mm)(dDb)*	260mm x 480mm x 174mm
Weight / Mass ( KG )	144kg
HS Code	8482300000
Original Country Show	CHINA

Spherical Roller Bearing List :

Bearing NO.	Principal Dimensions			Basic Load Ratings		Limiting Speeds		Shoulder Dia			Weight
	d	D	B	Cr	Cor	Grease	Oil	da (min)	Da (max)	ra (max)	Weight
	mm			KN		r/min		mm			(kg)
22206 CA	30	62	20	51.7	55	6800	9100	36	56	1	0.294
22207 CA	35	72	23	67	73.9	5900	7800	42	65	1	0.447
22208 CA	40	80	23	76.9	85	5200	6900	47	73	1	0.536
22209 CA	45	85	23	80.5	91.9	4900	6500	52	78	1	0.597
22210 CA	50	90	23	83.1	97.8	4500	6000	57	83	1	0.641
22211 CA	55	100	25	102	119	4100	5400	63	92	1.5	0.849
22212 CA	60	110	28	127	154	3700	4900	68	102	1.5	1.2
22213 CA	65	120	31	151	188	3400	4600	74	111	1.5	1.61
22214 CA	70	125	31	155	193	3200	4300	79	116	1.5	1.68
22215 CA	75	130	31	161	204	3100	4100	84	121	1.5	1.77
22216 CA	80	140	33	174	225	2900	3800	90	130	2	2.2
22217 CA	85	150	36	216	277	2700	3600	95	140	2	2.73
22218 CA	90	160	40	252	332	2500	3300	101	149	2	3.47
22219 CA	95	170	43	273	359	2400	3200	106	159	2.1	4.32
22220 CA	100	180	46	317	423	2200	3000	112	168	2.1	5.1
22222 CA	110	200	53	414	574	2000	2700	123	187	2.1	7.69
22224 CA	120	215	58	488	666	1900	2500	133	202	2.1	9.06
22226 CA	130	230	64	579	804	1800	2300	144	216	3	11.2
22228 CA	140	250	68	656	920	1600	2200	155	235	3	14.3
22230 CA	150	270	73	750	1060	1500	2000	165	255	3	18.1
22232 CA	160	290	80	879	1220	1400	1900	176	274	3	22.8
22234 CA	170	310	86	983	1380	1300	1800	187	293	4	29.2
22236 CA	180	320	86	1040	1490	1300	1700	197	303	4	30
22238 CA	190	340	92	1150	1700	1200	1600	208	322	4	37.3
22240 CA	200	360	98	1290	1910	1100	1500	219	341	4	43.2
22244 CA	220	400	108	1560	2260	1000	1400	240	380	4	59.5
22248 CA	240	440	120	1970	2870	750	950	258	422	3	80.7
22252 CA	260	480	130	2230	3350	670	850	282	458	4	107
22260 CA	300	540	140	2650	3980	750	1000	325	515	5	141
22264 CA	320	580	150	3000	4580	700	940	346	554	5	174
22280 CA	400	720	185	4550	7650	360	450	428	692	5	343

Spherical Roller Bearing 23252 CA／W33 260mm x 480mm x 174mm Contact with us freely !

Share this product to:

Let more people see your product

How can you buy 23252 CA／W33 Spherical Roller Bearing 260mm X 480mm X 174mm on the Internet?
High quality 23252 CA／W33 ( 144kg kg Mass, ID: 260 mm OD: 480 mm WD: 174 mm , P0 - P2 Accuracy Class , Grc15/Chrome Steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 23252 CA／W33. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
