231SM125-MA Bore 125 Mm, Spherical Roller Bearings Split, Metric Sizes, Solid Brass Cage

🔍

231SM125-MA

Bore Diameter:125 mm

Outside Diameter:225 mm

Width:110 mm

Weight:13.5 kg

Min. Order:1 Piece

The 231SM125-MA bearing is a Spherical roller bearings split, metric sizes with an inner diameter of 125 mm , an outer diameter of 225 mm, a width of 110 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 509537 N, its static radial rated load is approximately 749190 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

125 mm

Outside Diameter:

225 mm

Thickness:

110 mm

Weight:

13.5 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

509537 N

Static load Capacity, Radial (Cor):

749190 N

Fatigue Load Limit, Radial:

50310 N

Limiting speed (Oil rpm):

1112

Specifications:

Old Designations:

231SM125MA

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

MA = Solid brass cage

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to up +200 °C

Series:

231SM..-MA

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	231SM125-MA
Interchangeable	FAG 231SM125-MA
Bearing Type	Spherical roller bearings split, metric sizes
Splitted	SM = Split bearing metric
Bearing Mass - m [lb]	29.762
Rows NO.	Double row
Cage	MA = Solid brass cage
Design Type	E1A = without central rip
Replacement Bearing	23128K
Replacement Adapter sleeve	H3128
Dimension
Inside - d φ [mm]	125
Outside - D Φ [inch]	8.858
Width - B [inch]	4.331
Width - C [inch]	2.677
r(min.) [inch]	0.083
Performance
Radial Dynamic - C_r [lbf]	114543
Radial static - C_0r [lbf]	168417
Radial Fatigue - C_ur [lbf]	11309
Limiting speed - n_G [min^–1]	1112
Permissible axial load - F_a(max.) [lbf]	3089
Screw tightening torque - M_i [Nm]	35
Screw tightening torque - M_a [Nm]	9
Coefficient
e	0.28
Y₁	2.45
Y₂	3.64
Y₀	2.39
