23136E1A.M.C3 Double Row Spherical Roller Bearings, Main Dimensions To DIN 635-2

🔍

23136E1A.M.C3

Bore Diameter:180 mm

Outside Diameter:300 mm

Width:96 mm

Weight:26.907 kg

Min. Order:1 Piece

The 23136E1A.M.C3 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 23136E1A.M.C3 bearing is a Double row spherical roller bearings, main dimensions to DIN 635-2 with an inner diameter of 180 mm , an outer diameter of 300 mm, a width of 96 mm. GCr15, GCr15SiMn, SUJ2 rings, GCr15, SUJ2 rolling mlement. Its dynamic radial rated load is approximately 1419830 N, its static radial rated load is approximately 1949839 N. It uses C3 standard radial clearance, OPEN type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

180 mm

Outside Diameter:

300 mm

Thickness:

96 mm

Weight:

26.907 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

1419830

Static load Capacity, Radial (Cor):

1949839

Fatigue Load Limit, Radial:

198904

Reference speed (Grease rpm):

1326

Limiting speed (Oil rpm):

2209

Specifications:

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Bearing Material:

GCr15, GCr15SiMn, SUJ2

Cage Type:

M = Solid brass cage, guided by rollers

Seals Type:

OPEN

Rolling Mlement Material:

GCr15, SUJ2

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

231..-E1A

Rolling Element:

symmetrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

10 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

23136E1A.M.C3 bearings ( 180 mm x 300 mm x 96 mm) have the advantages of Self-aligning, high load-bearing capacity, impact resistant, and adaptable to heavy loads, and are therefore widely used in the Gearboxes, drive shafts, conveying equipment, general machinery.

Part Number	23136E1A.M.C3
Design Type	E1A = without central rip
Bore Type	Z = Cylindrical bore
RIC	C3
Row	2
Bearing Type	Double row spherical roller bearings, main dimensions to DIN 635-2
Manufacturer Part Code	23136-E1A-M-C3
Equivalent	23136-E1A-M-C3 , 23136E1A.M.C3
Cage	M = Solid brass cage, guided by rollers
Measurement	Metric
Seal type	OPEN
Relubrication	Standard
d φ Inside [inch]	7.087
D Φ Outside [inch]	11.811
B Width [inch]	3.780
n_B Reference speed (grease) [min^–1]	1326
n_G Limiting speed (oil) [min^–1]	2209
Weight [kg]	26.907
r(min.) Chamfer [inch]	0.118
D₁ [inch]	10.425
d_s [inch]	0.315
n_s [inch]	0.591
C_r Radial Dynamic [lbf]	319177
C_0r Radial static [lbf]	438323
C_ur Radial Fatigue [lbf]	44713
Temperature - T(min)[°C]	-30
Temperature - T(max)[°C]	+200
Mounting dimensions
d_a(min.) [inch]	7.638
D_a(max.) [inch]	11.260
r_a(max.) [mm]	26.907
Calculation coefficient
e	0.29
Y₀	2.26
Y₁	2.32
Y₂	3.45

The 23136E1A.M.C3 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
