231/800 CA/W33 Spherical Roller Bearings, Brass Cage

🔍

231/800 CA/W33

Bore Diameter:800 mm

Outside Diameter:1280 mm

Width:375 mm

Weight:1920 kg

Min. Order:1 Piece

The 231/800 CA/W33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 231/800 CA/W33 bearing is a Spherical roller bearings, double row with an inner diameter of 800 mm , an outer diameter of 1280 mm, a width of 375 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 18027878 N, its static radial rated load is approximately 31494902 N. It uses Normal standard radial clearance, open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

800 mm

Outside Diameter:

1280 mm

Thickness:

375 mm

Weight:

1920 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

18027878 N

Static load Capacity, Radial (Cor):

31494902 N

Reference speed (Grease rpm):

193

Limiting speed (Oil rpm):

394

Specifications:

Old Designations:

231/800CA/W33

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Normal

Bearing Material:

High-carbon chromium steel

Cage Type:

CA = brass cage

Seals Type:

open

Rolling Mlement Material:

High-carbon chromium steel

Bore Type:

Z = cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

231..-CA/W33

Rolling Element:

spherical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

231/800 CA/W33 bearings ( 800 mm x 1280 mm x 375 mm) have the advantages of Self-aligning, high load-bearing capacity, impact resistant, and adaptable to heavy loads, and are therefore widely used in the Gearboxes, drive shafts, conveying equipment, general machinery.

Part Number	231/800 CA/W33
Manufacturer Part Code	231/800CA/W33
Internal design	CA = Retaining flanges on the inner ring, guide ring centred on the inner ring, machined brass cage
Bearing Type	Spherical roller bearings, double row
m Weight [lb]	4232.832
Seal type	open
Series	231..-CA/W33
Cage	CA = brass cage
Lubrication	W33 = Annular groove and three lubrication holes in the outer ring
Bore Type	Z = cylindrical bore
Radial internal clearance	Normal
Units	Metric
C_r Dynamic Radial [lbf]	4052666
C_0r Static Radial [lbf]	7080053
P_u Fatigue Radial [lbf]	403339
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	+200
n_B Speed ratings (grease) [rpm]	193
n_G Speed ratings (oil) [rpm]	394
Heat stabilization	392 °F (200 °C)
Dimension
d φ Inside [inch]	31.496
D Φ Outside [inch]	50.394
B Width [inch]	14.764
b [inch]	0.878
K [inch]	0.472
d₂ [inch]	37.362
D₁ [inch]	44.921
r_a(max.) Fillet [inch]	0.315
r₁,r₂(min.) Fillet [inch]	0.374
Angular misalignment	1.5 degrees
Abutment dimensions
d_a(min.) [inch]	33.071
D_a(max.) [inch]	48.819
Calculation factor
e	0.28
Y₁	2.4
Y₂	3.6
Y₀	2.5

The 231/800 CA/W33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
