231/560CA/C3W33 Spherical Roller Bearings, Brass Cage

🔍

231/560CA/C3W33

Bore Diameter:560 mm

Outside Diameter:920 mm

Width:280 mm

Weight:740 kg

Min. Order:1 Piece

The 231/560CA/C3W33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 231/560CA/C3W33 bearing is a Spherical roller bearings, double row with an inner diameter of 560 mm , an outer diameter of 920 mm, a width of 280 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 9595593 N, its static radial rated load is approximately 15999337 N. It uses C3 standard radial clearance, open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

560 mm

Outside Diameter:

920 mm

Thickness:

280 mm

Weight:

740 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

9595593 N

Static load Capacity, Radial (Cor):

15999337 N

Reference speed (Grease rpm):

339

Limiting speed (Oil rpm):

627

Specifications:

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Bearing Material:

High-carbon chromium steel

Cage Type:

CA = brass cage

Seals Type:

open

Rolling Mlement Material:

High-carbon chromium steel

Bore Type:

Z = cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

231..-CA/W33

Rolling Element:

spherical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

231/560CA/C3W33 bearings ( 560 mm x 920 mm x 280 mm) have the advantages of Self-aligning, high load-bearing capacity, impact resistant, and adaptable to heavy loads, and are therefore widely used in the Gearboxes, drive shafts, conveying equipment, general machinery.

Part Number	231/560CA/C3W33
Manufacturer Part Code	231/560 CA/C3W33
Internal design	CA = Retaining flanges on the inner ring, guide ring centred on the inner ring, machined brass cage
Bearing Type	Spherical roller bearings, double row
m Weight [lb]	1631.404
Seal type	open
Series	231..-CA/W33
Cage	CA = brass cage
Lubrication	W33 = Annular groove and three lubrication holes in the outer ring
Bore Type	Z = cylindrical bore
Radial internal clearance	C3
Units	Metric
C_r Dynamic Radial [lbf]	2157089
C_0r Static Radial [lbf]	3596650
P_u Fatigue Radial [lbf]	220240
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	+200
n_B Speed ratings (grease) [rpm]	339
n_G Speed ratings (oil) [rpm]	627
Heat stabilization	392 °F (200 °C)
Dimension
d φ Inside [inch]	22.047
D Φ Outside [inch]	36.220
B Width [inch]	11.024
b [inch]	0.878
K [inch]	0.472
d₂ [inch]	26.575
D₁ [inch]	31.850
r_a(max.) Fillet [inch]	0.236
r₁,r₂(min.) Fillet [inch]	0.295
Angular misalignment	1.5 degrees
Abutment dimensions
d_a(min.) [inch]	23.307
D_a(max.) [inch]	34.961
Calculation factor
e	0.3
Y₁	2.3
Y₂	3.4
Y₀	2.2

The 231/560CA/C3W33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
