23096CA/C4W33 Spherical Roller Bearings, Brass Cage

🔍

23096CA/C4W33

Bore Diameter:480 mm

Outside Diameter:700 mm

Width:165 mm

Weight:215 kg

Min. Order:1 Piece

The 23096CA/C4W33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 23096CA/C4W33 bearing is a Spherical roller bearings, double row with an inner diameter of 480 mm , an outer diameter of 700 mm, a width of 165 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 3995879 N, its static radial rated load is approximately 6799202 N. It uses C4 standard radial clearance, open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

480 mm

Outside Diameter:

700 mm

Thickness:

165 mm

Weight:

215 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

3995879 N

Static load Capacity, Radial (Cor):

6799202 N

Reference speed (Grease rpm):

528

Limiting speed (Oil rpm):

937

Specifications:

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Bearing Material:

High-carbon chromium steel

Cage Type:

CA = brass cage

Seals Type:

open

Rolling Mlement Material:

High-carbon chromium steel

Bore Type:

Z = cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

230..-CA/W33

Rolling Element:

spherical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

23096CA/C4W33 bearings ( 480 mm x 700 mm x 165 mm) have the advantages of Small cross-section, high load-bearing capacity, self-aligning, and low friction, and are therefore widely used in the Gearbox, motor, space-constrained transmission components.

Part Number	23096CA/C4W33
Manufacturer Part Code	23096 CA/C4W33
Internal design	CA = Retaining flanges on the inner ring, guide ring centred on the inner ring, machined brass cage
Bearing Type	Spherical roller bearings, double row
m Weight [lb]	473.989
Seal type	open
Series	230..-CA/W33
Cage	CA = brass cage
Lubrication	W33 = Annular groove and three lubrication holes in the outer ring
Bore Type	Z = cylindrical bore
Radial internal clearance	C4
Units	Metric
C_r Dynamic Radial [lbf]	898273
C_0r Static Radial [lbf]	1528460
P_u Fatigue Radial [lbf]	101001
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	+200
n_B Speed ratings (grease) [rpm]	528
n_G Speed ratings (oil) [rpm]	937
Heat stabilization	392 °F (200 °C)
Dimension
d φ Inside [inch]	18.898
D Φ Outside [inch]	27.559
B Width [inch]	6.496
b [inch]	0.878
K [inch]	0.472
d₂ [inch]	21.614
D₁ [inch]	24.921
r_a(max.) Fillet [inch]	0.197
r₁,r₂(min.) Fillet [inch]	0.236
Angular misalignment	1.5 degrees
Abutment dimensions
d_a(min.) [inch]	19.803
D_a(max.) [inch]	26.653
Calculation factor
e	0.21
Y₁	3.2
Y₂	4.8
Y₀	3.2

The 23096CA/C4W33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
