23064-2CS5/VT143 Spherical Roller Bearings, Stamping Steel Cage

🔍

23064-2CS5/VT143

Bore Diameter:320 mm

Outside Diameter:480 mm

Width:121 mm

Weight:7.55 kg

Min. Order:1 Piece

The 23064-2CS5/VT143 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.

The 23064-2CS5/VT143 bearing is a Sealed spherical roller bearings with an inner diameter of 320 mm , an outer diameter of 480 mm, a width of 121 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 2342904 N, its static radial rated load is approximately 3794846 N. It uses Normal standard radial clearance, 2CS5 = Contact seal, HNBR, on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

320 mm

Outside Diameter:

480 mm

Thickness:

121 mm

Weight:

7.55 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

2342904 N

Static load Capacity, Radial (Cor):

3794846 N

Limiting speed (Oil rpm):

300

Specifications:

Structure:

Spherical Roller Bearings

Number of Rows:

Radial Clearance Trade No.:

Normal

Bearing Material:

High-carbon chromium steel

Cage Type:

Stamping steel cage

Seals Type:

2CS5 = Contact seal, HNBR, on both sides

Rolling Mlement Material:

High-carbon chromium steel

Bore Type:

Z = cylindrical bore

Operating Temperature:

-30 to +200 °C

System of Measurement:

Metric

Series:

230..-2CS5/VT143

Rolling Element:

spherical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

23064-2CS5/VT143 bearings ( 320 mm x 480 mm x 121 mm) have the advantages of Small cross-section, high load-bearing capacity, self-aligning, and low friction, and are therefore widely used in the Gearbox, motor, space-constrained transmission components.

Part Number	23064-2CS5/VT143
Manufacturer Part Code	23064-2CS5/VT143
Bearing Type	Sealed spherical roller bearings
m Weight [lb]	16.645
Seal type	2CS5 = Contact seal, HNBR, on both sides
Series	230..-2CS5/VT143
Cage	Stamping steel cage
Lubrication	VT143 = Filled to 25 – 45% with SKF LGEP 2 grease
Bore Type	Z = cylindrical bore
Radial internal clearance	Normal
Units	Metric
C_r Dynamic Radial [lbf]	526684
C_0r Static Radial [lbf]	853081
P_u Fatigue Radial [lbf]	62867
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	+200
n_G Speed ratings (oil) [rpm]	300
Heat stabilization	392 °F (200 °C)
Dimension
d φ Inside [inch]	12.598
D Φ Outside [inch]	18.898
B Width [inch]	4.764
b [inch]	0.657
K [inch]	0.354
d₂ [inch]	13.937
D₁ [inch]	17.638
r_a(max.) Fillet [inch]	0.118
r₁,r₂(min.) Fillet [inch]	0.157
Angular misalignment	1.5 degrees
Abutment dimensions
d_a(min.) [inch]	13.189
d_a(max.) [inch]	13.937
D_a(max.) [inch]	18.307
Calculation factor
e	0.23
Y₁	2.9
Y₂	4.4
Y₀	2.8

The 23064-2CS5/VT143 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.

Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
