23060 CCK/W33 Spherical Roller Bearings, Stamped Steel Cages, Tapered Bore
The 23060 CCK/W33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.
The 23060 CCK/W33 bearing is a Spherical roller bearings, double row with an inner diameter of 300 mm , an outer diameter of 460 mm, a width of 118 mm. High-carbon chromium steel rings, High-carbon chromium steel rolling mlement. Its dynamic radial rated load is approximately 2213844 N, its static radial rated load is approximately 3444958 N. It uses Normal standard radial clearance, open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
23060 CCK/W33 bearings ( 300 mm x 460 mm x 118 mm) have the advantages of Small cross-section, high load-bearing capacity, self-aligning, and low friction, and are therefore widely used in the Gearbox, motor, space-constrained transmission components.
| Part Number | 23060 CCK/W33 |
| Manufacturer Part Code | 23060CCK/W33 |
| Internal design | CC = Flangeless inner ring, guide ring centred on the inner ring, two stamped steel cages |
| Bearing Type | Spherical roller bearings, double row |
| m Weight [lb] | 157.629 |
| Seal type | open |
| Series | 230..-CCK/W33 |
| Cage | CC = stamped steel cages |
| Lubrication | W33 = Annular groove and three lubrication holes in the outer ring |
| Bore Type | K = Tapered bore, taper 1:12 |
| Radial internal clearance | Normal |
| Units | Metric |
| Cr Dynamic Radial [lbf] | 497672 |
| C0r Static Radial [lbf] | 774426 |
| Pu Fatigue Radial [lbf] | 58295 |
| Operating temperature - T(min) [°C] | -30 |
| Operating temperature - T(max) [°C] | +200 |
| nB Speed ratings (grease) [rpm] | 1183 |
| nG Speed ratings (oil) [rpm] | 1419 |
| Heat stabilization | 392 °F (200 °C) |
| Dimension | |
| d φ Inside [inch] | 11.811 |
| D Φ Outside [inch] | 18.110 |
| B Width [inch] | 4.646 |
| b [inch] | 0.657 |
| K [inch] | 0.354 |
| d2 [inch] | 13.386 |
| D1 [inch] | 16.299 |
| ra(max.) Fillet [inch] | 0.118 |
| r1,r2(min.) Fillet [inch] | 0.157 |
| Angular misalignment | 1.5 degrees |
| Abutment dimensions | |
| da(min.) [inch] | 12.402 |
| Da(max.) [inch] | 17.520 |
| Calculation factor | |
| e | 0.23 |
| Y1 | 2.9 |
| Y2 | 4.4 |
| Y0 | 2.8 |
The 23060 CCK/W33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.
Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
