23048 CC/C08W33 Bore 240 Mm, Stamped Steel Cages, Spherical Roller Bearings, ABEC 5 Running Accuracy
The 23048 CC/C08W33 Double-row spherical roller bearings are suitable for heavy-load, impact, and eccentric conditions. Classic applications include vibrating screen exciters, crushers, fans, paper machine press rolls, mining conveyor equipment, and marine propulsion shafts.
The 23048 CC/C08W33 bearing is a Spherical roller bearings, double row with an inner diameter of 240 mm , an outer diameter of 360 mm, a width of 92 mm. It typically uses P5 grade precision tolerances and GCr15SiMn rings, GCr15SiMn rolling mlement. It uses Normal standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
23048 CC/C08W33 bearings ( 240 mm x 360 mm x 92 mm) have the advantages of Small cross-section, high load-bearing capacity, self-aligning, and low friction, and are therefore widely used in the Gearbox, motor, space-constrained transmission components.
| Part Number | 23048 CC/C08W33 |
| Bearing Type | Spherical roller bearings, double row |
| Internal design | CC = Flangeless inner ring, guide ring centred on the inner ring, two stamped steel cages |
| Reference From | SKF 23048 CC/C08W33 |
| Cage | CC = stamped steel cages |
| Accuracy class | P5 |
| Seal | Open |
| Internal clearance | Normal |
| Weight [lb] | 71.650 |
| Permissible angular misalignment | 2.5 degrees |
| Heat stabilization | 392 °F (200 °C) |
| Roller bearing type | Spherical |
| Lubrication | W33 = Annular groove and three lubrication holes in the outer ring |
| Bore Type | Z = cylindrical bore |
| Other variants | C08 = ABEC 5 running accuracy, inner and outer rings |
| Principal Dimensions | |
| Inside - d φ [inch] | 9.449 |
| Inside - d φ tolerance | -0.03 mm to 0 |
| Outside - D Φ [inch] | 14.173 |
| Outside - D Φ tolerance | -0.04 mm to 0 |
| Width - B [inch] | 3.622 |
| Width - B tolerance | -0.08 mm to 0 |
| d2 [inch] | 10.669 |
| D1 [inch] | 12.835 |
| b [inch] | 0.547 |
| K [inch] | 0.295 |
| r1,r2(min.) [inch] | 0.118 |
| Performance | |
| Dynamic Radial - Cr [lbf] | 301149 |
| Static Radial - C0r [lbf] | 467353 |
| Speed ratings (oil) - nG [rpm] | 1872 |
The 23048 CC/C08W33 Double-row spherical roller bearings mainly consist of an inner ring, an outer ring, two rows of spherical rollers, a cage, and seals. The outer ring raceway has a spherical structure, while the inner ring has a double-row raceway. The rollers and raceways are logarithmically curved. The cage is typically made of stamped steel or machined brass.
Double-row spherical roller bearings possess excellent self-aligning properties, compensating for shaft deflection, installation errors, and misalignment. They can simultaneously withstand radial loads and bidirectional axial loads, exhibiting extremely high load-bearing capacity and strong impact resistance. Furthermore, the internal clearance can be optimized for vibration conditions, effectively reducing frictional temperature rise.
