22326CAK/W33 (Size:130x280x93mm) High Load Spherical Roller Bearing
The 22326CAK/W33 bearing is a Spherical Roller Bearings with an inner diameter of 130 mm , an outer diameter of 280 mm, a width of 93 mm. Chrome Steel (Gcr15) rings. Its dynamic radial rated load is approximately 1060 (kN), its static radial rated load is approximately 1300 (kN). together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Application: Mining equipment (powdering machines, vibrating screens, conveyors, etc.), gearboxes, air preheaters, extruders, centrifugal separators, construction machinery, steelmaking machinery, papermaking machines
22326CAK/W33 Spherical Roller Bearing, High load capacity, Suited for applications involving large radial loads, heavy loads, and impact loads.
Size: 130x280x93mm
Inner Diameter (d): 130mm
Outer Diameter (D): 280mm
Thickness (B): 93mm
|
Bearing Part No. |
Basic Dimensions (mm) |
Basic Load Rating (kN) |
Speed Ratings (rpm) |
Other Dimensions (mm) |
Contact Surface and Chamfer Dimension |
Calculation Factors |
Weight (kg) |
|||||||||||||
|
d |
D |
B |
rmin |
Dynamic (Cr ) |
Static (Cor) |
Grease |
Oil |
d2 |
D1 |
b |
k |
da |
Da |
ra |
e |
Y1 |
Y2 |
Y0 |
||
|
22326CAK/W33 |
130 |
280 |
93 |
4 |
1060 |
1300 |
1300 |
1700 |
178 |
232 |
16.7 |
6 |
148 |
262 |
3 |
0.34 |
1.99 |
2.96 |
1.94 |
27.8 |
22326CAK/W33 Spherical Roller Bearings have two rows of spherical rollers, the outer ring has a common concave spherical raceway, the inner ring has two concave raceways that are inclined at an angle to the bearing axis, the curvature center of the outer ring raceway is the same as the bearing center.
Spherical roller bearings are self-aligning and are not affected by misalignment of the shaft and bearing box or deflection of the shaft, and can compensate for the resulting concentricity errors. In addition to bearing radial load, this type of bearing can also bear two-way axial load and its combined load. It has a large bearing capacity and good vibration and impact resistance.
All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please contact us by e-mail, wechat , whatsapp or skype.
